GM-8027ZT/WL
6.1 ASL SECTION ADJUSTMENT
Note:
1) Only if ASL parts (shaded ones below) get changed, you need adjustments for ASL.
2) When you disconnect the connector for ASL, you need to be careful.
Refer to the sentence and the figure below.
When you disconnect the Cord Assy (CDE6990) that connects between DSP PCB and Microphone PCB,
get your hand on the connector.
Never pull the cable directly because it's very week and easy to be cut.
Hook your pointed fingers' nail, and you can disconnect it easily.
