GM-8027ZT/WL
C 378 CKSQYB473K16
C 379 CEJQ2R2M50
C 380 CEJQ1R0M50
C 381 CKSQYB474K25
C 382 CKSQYB474K25
C 383 CEJQ100M16
C 384 CKSQYB104K25
C 391 CKSQYB102K50
C 392 CKSQYB102K50
C 393 CKSQYB102K50
C 394 CKSQYB102K50
C 395 CKSQYB102K50
C 401 CEAT470M10
C 402 CEAT470M10
C 403 0.68µF/50V CCH1386
C 404 CEAT100M50
C 405 CEAT470M10
C 406 CCSQCH101J50
C 407 CEAT470M10
C 408 CEAT100M50
C 409 CKSQYB683K25
C 410 CEANP220M10
C 411 CKSQYB823K25
C 412 CEANP100M16
C 413 CEANP100M16
C 414 CKSQYB103K50
C 415 CEANP100M16
C 451 CEJQ221M6R3
C 452 CEJQ221M6R3
C 453 CKSQYB104K25
Unit Number : CWM8077(GM-8027ZT/WL)
: CWM8075(GM-8027ZT/E)
: CWM8355(GM-8127ZT/WL)
: CWM8352(GM-8127ZT/EW)
Unit Name : Amp Unit
MISCELLANEOUS
IC 501 IC NJM2068MD
IC 502 IC NJM2068MD
IC 701 IC NJM2068MD
IC 702 IC NJM2068MD
IC 703 IC NJM2068MD
IC 801 IC PAL006A
IC 802 IC PAL006A
IC 803 IC PAL006A
IC 901 IC NJM2930F08K
IC 902 IC BA178M05T
IC 903 IC M51957BFP
Q 801 Transistor DTA124EK
Q 802 Transistor DTA124EK
Q 803 Transistor DTA124EK
Q 831 Chip Transistor 2SC2712
Q 832 Chip Transistor 2SC2712
Q 833 Chip Transistor 2SC2712
Q 903 Transistor 2SC3651
Q 904 Transistor 2SB1260
Q 906 Transistor 2SB1260
Q 907 Transistor 2SA1587
Q 909 Transistor DTC114EK
Q 910 Transistor DTA114EK
Q 911 Transistor 2SD1757K
Q 912 Transistor DTC114EK
Q 913 Transistor DTC144EK
Q 915 Transistor DTA114TK
Q 916 Transistor 2SA1162
Q 950 Chip Transistor 2SC2712
D 901 Diode RM4LFJ10
D 902 Diode 1SS355
D 904 Diode 1SS355
D 905 Diode ERA15-02VH
D 906 Diode UDZS5R6(B)
D 907 Diode HZU4R3(B3)
D 909 Diode MA152WK
D 910 Diode 1SS355
D 911 Diode MA152WK
D 916 Diode UDZS18(B)
D 917 Diode UDZS18(B)
D 950 Diode UDZS7R5(B)
L 901 Choke Coil 260mH CTH1240
RESISTORS
R 501 RS1/10S103J
R 502 RS1/10S103J
R 503 RS1/10S103J
R 504 RS1/10S103J
R 505 RS1/10S472J
R 506 RS1/10S472J
R 507 RS1/10S472J
R 508 RS1/10S472J
R 509 RS1/10S822J
R 510 RS1/10S822J
R 511 RS1/10S822J
R 512 RS1/10S822J
R 517 RS1/10S153J
R 518 RS1/10S153J
R 519 RS1/10S153J
R 520 RS1/10S153J
R 521 RS1/10S101J
R 522 RS1/10S101J
R 523 RS1/10S101J
R 524 RS1/10S101J
R 701 RS1/10S223J
R 702 RS1/10S223J
R 703 RS1/10S223J
R 704 RS1/10S223J
R 705 RS1/10S303J
R 706 RS1/10S303J
R 707 RS1/10S223J
R 708 RS1/10S223J
R 709 RS1/10S123J
R 710 RS1/10S123J
R 711 (GM-8027ZT/WL) RS1/10S103J
R 711 (GM-8127ZT/WL,GM-8127ZT/EW) RS1/10S392J
R 711 (GM-8027ZT/E) RS1/10S472J
R 712 (GM-8027ZT/WL) RS1/10S103J
R 712 (GM-8127ZT/WL,GM-8127ZT/EW) RS1/10S392J
R 712 (GM-8027ZT/E) RS1/10S472J
R 713 RS1/10S223J
R 714 (GM-8027ZT/WL,GM-8127ZT/WL) RS1/10S223J
R 714 (GM-8027ZT/E) RS1/10S183J
R 714 (GM-8127ZT/EW) RS1/10S153J
R 715 (GM-8027ZT/WL,GM-8127ZT/WL,GM-8127ZT/EW)
RS1/10S151J
R 715 (GM-8027ZT/E) RS1/10S471J
R 716 (GM-8027ZT/WL,GM-8127ZT/WL,GM-8127ZT/EW)
RS1/10S151J
R 716 (GM-8027ZT/E) RS1/10S471J
R 717 (GM-8027ZT/WL,GM-8127ZT/WL,GM-8127ZT/EW)
RS1/10S392J
R 717 (GM-8027ZT/E) RS1/10S332J
R 718 (GM-8027ZT/WL,GM-8127ZT/WL,GM-8127ZT/EW)
RS1/10S392J
R 718 (GM-8027ZT/E) RS1/10S332J
R 719 RS1/10S221J
R 721 RS1/10S474J
=====Circuit Symbol and No.===Part Name Part No.
--- ------ ------------------------------------------ -------------------------
=====Circuit Symbol and No.===Part Name Part No.
--- ------ ------------------------------------------ -------------------------
