7. GENERAL INFORMATION
1. Service Mode Summary
This unit is controlled with two microcomputers. One microcomputer performs the button input and indication of FL and LED
(display section), and the other microcomputer drives the player (player section).
Test mode is prepared in each microcomputer.
1 Confirmation mode of the button of display section and display function
It is the mode which confirms button input and display function.
2 The mode which confirms the operation of the player section (use the remote control unit)
Connect the remote control unit (RU-V101) to the data copy terminal of the player, and confirms the operation.
3 Version confirmation mode
Can confirm software version of each microcomputer.
2. Confirmation Mode of the Button of Display Sectiont and Display Function
Enter this mode when turns the power on while pressing the [MEMORY] key and [TIME] key simultaneously.
It can light display part in this mode partially as follows. And it can perform each button and the input of volume and indication
normally. Further, display lights while pressing the button.
Button Display
LED
QUICK RETURN
Light LED of QUICK RETURN
AUTO BEAT (1, 2, 4, 8)
Light LED of each beat
REVERSE
Light LED of REVERSE
CUE
Light LED of CUE
PLAY/PAUSE
Light LED of PLAY/PAUSE
LOOP IN
Light LED of LOOP IN
LOOP OUT
Light LED of LOOP OUT
JOG MODE
Light LED of VINYL
TEMPO RANGE
Light LED of TEMPO RANGE
MASTER TEMPO
Light LED of MASTER TE M PO
FL
TRACK/SEARCH - FWD
Light "REMAIN", "M", " : ", "88" of a minute and "8" of high-order digit of a second
TRACK/SEARCH - REV
Light "88" of the track number, "A. COU" and "QUICK RETURN"
SEARCH - FWD
Light "S", "F", "8" of low order digit of a second and "88" of a frame
SEARCH -REV
Light all of Playing bar and frame
TIME MODE/AUTO CUE
Light "+1888%" of tempo, "888" of BPM, "WIDE", "MT" and "BPM"
RELOOP/EXIT
Light all FLs, JOG-FLs and LEDs of the main unit
CALL
Light all the rotation display parts of JOG-FL
MEMORY
Light all CUE point marks of JOG-FL
EJECT
Light "VINYL" character and a frame (blue) of the JOG-FL center
JOG ADJUST VOLUME
Goes out the ring A of JOG-FL when the volume position is less than the center. And
light it when it is more than the center.
SLIDER VOLUME
Goes out the ring B of JOG-FL when the volume position is less than the center. And
light it when it is more than the center.
