5.3 IC INFORMATION
• Pin Function
(M3030RFGPFP_256k)(CPU Assy: IC2023)
MAIN UCOM
No. Symbol I/O Description
1 A_MUTE O Audio output control pins at Mute Tr (active at L)
2 DC/DC_ON2 O Control pin DC/DC IC +5V (on: H)
3 F_RLY O Tr driven control pins at the Front speaker output relay. (active at H)
4 S_RLY O Tr driven control pins at the Surround speaker output relay. (active at H)
5 C_RLY O Tr driven control pins at the Center speaker output relay.(active at H)
6 AC_VOLT_DET Not used
7 RMC I Remote control signal input pin
8GND Ground
9CNVSS_UP I Switches processor mode
10 24C16_SDA I/O Data signal input & output for data backup of MAIN UCOM
11 24C16_SCL O Clock signal output for data backup of MAIN UCOM
12 RESET I Microcomputer reset signal input pin (active at L)
13 XOUT O Output for 16 MHz crystal
14 GND Ground
15 XIN I Input for 16 MHz crystal
16 3V3 +3.3 V power supply
17 NMI Pull up
18 TUNER_INT I Tuner Interrupt signal input pin
19 PDN O Output for MAIN UCOM power down
20 OSD/FLT_DATA O OSD or FLT Data pin
21 MUTE_B+_CTL O Power control pin mute B+
22 VIDEO_MUTE O Output for video IC MUTE condition
23 HP_DET I Monitoring the input pin headphone connection
24 OSD_CE O OSD IC enable signal output and UPGRADE pin
25 V5+V_DET I Detection pin V+5V protection (Not used)
26 V_CTL_A O IC control signal A output pin for selecting the video input
27 V_CTL_B O IC control signal B output pin for selecting the video input
28 OSD/FLT_CLK O OSD & FL drive IC output pin of the Clock
29 NCONot used
30 NCONot used
31 232_RX/U_TX O Output for Upgrade (UART)
32 232TX/U_RX I Input for Upgrade (UART)
33 SCLK_JTAG I Serial clock input and Protection pin
34 BUSY_JTAG O Output for JTAG BUSY/TRIGER1_ON/OFF SIGNAL
35 3959_SDA I/O MFI IC DATA signal
36 3959_SCL I/O MFI IC CLK signal
37 PULL_DOWN PULL_DOWN
38 HDMI_3V3_ON O Control pin HDMI IC +3.3V (on: H)
39 OSD_RESET O OSD IC reset signal output pin
40 TUNER_SCLK O Clock signal output for Tuner Pack
41 EPM_UP I UPGRADE
42 TUNER_SDIO I/O Data signal input & output for Tuner Pack
43 TUNER_SEN O Output for Tuner Pack Serial Enable Input (active at L)
44 TUNER_RST O Output to reset Tuner Pack (active at L)
45 D+3.3V_ON O Control pin DSP IC +3.3V (on: H)
46 U_CE O OSD IC enable signal output and UPGRADE pin
47 3959_PWR O MFI IC Power control pin
48 3959_RESET O MFI IC reset signal
49 VOL_DATA O Data signal output for R2A15219 (I2C)
50 VOL_CLK O CLK signal output for R2A15219 (I2C)
