HTV-SW1, HTV-C1
4
Mark No. Description Part No.
÷ EXTERIOR(Cabinet HTV-SW1) PARTS
LIST
NSP 1 Cabinet SMM1821
NSP 2 Power AMP HTV-A1/DDXJ
3 Connecting Cord SDF1072
NSP 4 Paper Port tube SMR1283
5 Foot SNK2274
NSP 6 CAUTION LABEL SRR1012
7 Speaker Q20EU82-52F
8 Screw BYC40P200FZB
9 Bind Tapping Screw BYC40P300FZK
NSP 10 Logo 40 SAM1452
2.1.2 EXTERIOR ( Cabinet HTV-SW1 )
5
3
9
9
10
4
1
A
2
8
8
8
Refer to "2.1.3 POWER AMP SECTION"
A
A
6
7
8
8
5
