HTV-SW1, HTV-C1
6
•
EXTERIOR(POWER AMP HTV-A1) PARTS LIST
1 AFPS ASSY AWU7262
2 PAMP ASSY AWU7263
3 PT PRI ASSY AWU7264
4 PT SEC ASSY AWU7265
5 JACK ASSY AWU7257
6 Power Transformer (T1) ATS7228
7 Fuse (FU1 : T3.15AL250V) REK1027
8 Fuse (FU2, 3 : T1.6AL250V) REK1024
9 AC Power Cord VDG1058
NSP 10 Chassis ANA7093
NSP 11 Heat Sink ANH7079
12 PW Barrier AEC7157
13 ST Barrier AEC7155
14 TRANS Frame ANG7216
15 Mini Card Spacer AEC7143
16 Mica Sheet AEE7010
17 Strain Relief CM-22B
NSP 18 PCB Holder PNW2174
19 Bonnet Case AZN7214
20 PCB Stay ANG7217
21 Screw ABA-258
22 Screw ASZ40P060FMC
23 Screw BBZ30P080FMC
24 Screw IBZ30P080FMC
25 STANDBY PT Assy AWU7267
26 PW SWITCH Assy AWU7259
27 Connector Assy 6P ADX7245
NSP 28 Cord Support Assy • • • • •
29 Push Rivet AEC7149
30 Cushion AEB7123
31 Heat Protector AEC7136
NSP 32 Volt Selector Label AAX7667
NSP 33 POWER SW Label AAX7669
