Pioneer M-LA21 - Page 7

M-LA21
7
A
B
C
D
5
678
5
6
7
8
TRANSFORMER
ASSY
(PMT1LA100031)
B
PRIMAY ASSY
(PMT1LA100041)
C
AC IN
PHONES
HP JACK ASSY
(PMT1LA100111)
G
LED ASSY
(PMT1LA100051)
F
: AUDIO SIGNAL ROUTE
(PH)
(PH)
From
XC-LA21
3
: AUDIO SIGNAL ROUTE (PHONES)
(PH)
D311
Note : When ordering service parts, be sure to refer to "EXPLODED VIEWS and PARTS LIST" or "PCB PARTS LIST".
