Pioneer PDP-427CMX - Page 14

PDP-427CMX
14
1234
1234
C
D
F
A
B
E
R2019,2020 RS1/8SQ0R0J
Other Resistors RS1/10SR###J
CAPACITORS
C2001-2007 CCSRCH101J50
C2008,2011-2013,2016 CKSRYB104K50
C2009,2010 CKSRYB104K25
C2014,2015,2019-2021 CCSRCH471J50
C2017,2022-2024 CKSRYB104K50
C2018 CEHVKW470M16
COMMSLOT IF ASSY (AWW1222)
SEMICONDUCTORS
IC2301 TC74VHC00FT
Q2301,2351 2SC4081
Q2302 DTC144EUA
Q2350 HN1A01FU
MISCELLANEOUS
CN2302 40P SIDE CONNECTOR AKM1347
CN2303 EDGE CARD CONN 46P AKP1252
CN2301 L PLUG ( 8P ) KM200NA8L
RESISTORS
R2313 RS1/8SQ0R0J
R2350 RS1/10SR1502F
R2351,2353 RS1/10SR1202F
R2354 RS1/10SR1002F
R2355 RS1/10SR2201F
Other Resistors RS1/10SR###J
CAPACITORS
C2301 CKSRYB104K50
C2350,2351 CKSRYB104K25
KEY ASSY (AWW1223)
SEMICONDUCTORS
IC2201 PD5719A
Q2201 2SC4081
D2201 1SS355
MISCELLANEOUS
S2201-2208 VSG1020
>
X2201 CERALOCK (3.84MHz) ASS1162
CN2201 3PIN CONNECTOR S3B-EH
RESISTORS
R2204,2207 RS1/10SR2202F
R2210 RAB4CQ182J
Other Resistors RS1/10SR###J
CAPACITORS
C2201,2202,2205 CKSRYB472K50
C2203,2204,2208 CCSRCH101J50
C2206 CKSRYB104K50
C2207 CEHVKW470M6R3
LED2 ASSY (AWW1224)
Mark No. Description Part No.
SEMICONDUCTORS
Q2401 HN1B04FU
Q2403-2405 2SC4081
Q2406 2SA1576A
D2401 S9561
D2402 SPR-39MVWF
MISCELLANEOUS
CN2401 CONNECTOR 8P AKM1294
U2401 REMOTE RECEIVER UNIT RPM6940-V4
RESISTORS
R2416-2419 RS1/8SQ130J
All Resistors RS1/10SR###J
CAPACITORS
C2401,2405,2409 CKSRYB104K25
C2402-2404 CKSRYF105Z16
C2407,2408 CEHVKW470M16
C339,340,343,344 CKSQYB105K16
C341 CKSQYB474K25
C342 BCG1060
C346 CCSRCH151J50
C353 CKSRYB104K25
Mark No. Description Part No.
