5. PCB PARTS LIST
77
77
CONTRAST OF PCB ASSEMBLIES
AWW1100 and AWW1112 are constructed the same except for the following :
AWW1101 and AWW1113 are constructed the same except for the following :
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
561
473
R50
1R0
5621
NOTES:
560 Ω
47k Ω
0.5 Ω
1 Ω
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 10
3
R50
1R0
561
473
5.62k Ω RN1/4PC F562 x 10
1
5621
MarkNo. Description Part No.
LIST OF ASSEMBLIES
NSP 1..PANEL CHASSIS (FT) ASSY AWU1136
NSP 2..42 ADDRESS ASSY AWV2253
NSP 2..42 SCAN ASSY AWV2252
NSP 3..42 SCAN A ASSY AWW1071
NSP 3..42 SCAN B ASSY AWW1072
NSP 1..42 X DRIVE ASSY AWV2250
2..42 X DRIVE ASSY AWW1067
2..SUS CLAMP 1 ASSY AWW1022
2..SUS CLAMP 2 ASSY AWW1023
1..43 Y DRIVE ASSY AWV2251
1..MD DIGITAL ASSY AWV2254
1..MAIN ASSY (for 425CMX) AWV2285
2..MAIN ASSY (for 425CMX) AWW1100
2..VSIF ASSY (for 425CMX) AWW1101
1..MAIN ASSY (for 42MXE10) AWV2286
2..MAIN ASSY (for 42MXE10) AWW1112
2..VSIF ASSY (for 42MXE10) AWW1113
1..SUB ASSY AWV2287
2..SENB ASSY AWW1102
2..SENC ASSY AWW1103
2..SEND ASSY AWW1104
2..AUDIO ASSY AWW1105
2..COMMSLOT ASSY AWW1106
2..COMMSLOT IF ASSY AWW1107
2..KEY ASSY AWW1108
2..LED2 ASSY AWW1109
> 1..POWER SUPPLY UNIT AXY1127
MAIN ASSY
Mark Symbol and Description AWW1100 AWW1112
R9111 RS1/10SR0R0J Not used
R9112 Not used RS1/10SR0R0J
R9113 RS1/10SR0R0J Not used
R9114 Not used RS1/10SR0R0J
VSIF ASSY
Mark Symbol and Description AWW1101 AWW1113
R4042 RS1/10SR0R0J Not used
R4043 Not used RS1/10SR0R0J
Mark No. Description Part No.
MAIN ASSY (425CMX)
MAIN BLOCK1
SEMICONDUCTORS
IC9508 24LC128(I)SN
IC9505 BD4727G
IC9506 MC74VHCT132ADT
>
IC9503 NJM2846DL3-33
>
IC9502 PQ1U501M2ZPH
IC9507 RTC-4543SA-B-7
IC9504 SN74LVC08APW
IC9509 TC74VHCT08AFTS1
Q9503 2SA1576A
D9501, D9502, D9504, D9506 DAN202U
D9508 MZ2J73200L
D9507 RB751S-40
D9514, D9521 RD3R3S(B1)
COILS AND FILTERS
F9501-F9503 DTL1034
CAPACITORS
C9508 (4.7/16) ACG1134
C9517 (1000/10) ACH1431
BT9501 AEX1030
C9531, C9532 CCSRCH100D50
C9510, C9525, C9547 CCSRCH102J50
Mark No. Description Part No.
