[QS1]: To acquire data on the various version information
Order Data Contents Size Remarks
1 STX 1Byte 02hex
2 Command echo back 3Byte QS1 (fixed)
3 Panel resolution / size information 1Byte 3 (fixed)
4 Panel generation information 1Byte 6 (fixed)
5 Panel destination information 1Byte ∗ (fixed)
6 Panel grade 1Byte ∗ (fixed)
7 Panel product form 1Byte D (fixed)
8 Boot version of module microcomputer 3Byte
9 Program version of module microcomputer 8Byte
10 Boot version of Astra 3Byte
11 Program version of Astra 8Byte
12 Sequence version (42/43VIDEO) 4Byte
13 Sequence version (42/43PC) 4Byte
14 Sequence version (50/61VIDEO) 4Byte
15 Sequence version (50/61PC) 4Byte
16 Simplicity / multi-function operation mode information 1Byte L (fixed)
17 Delimiter 1Byte , (comma)(fixed)
18 Dummy 4Byte
19 Program version of main microcomputer 8Byte
20 Dummy 40Byte
21 Check sum 2Byte
22 ETX 1Byte 03hex
[QS4]: To acquire data on the factory information
Input signal classification
Order Data Contents Size Remarks
1 STX 1Byte 02hex
2 Command echo back 3Byte QS4 (fixed)
3 Main input function 3Byte As the same contents as item 9 of QST command
4 Input signal classification 1Byte Refer to the following table
5 Vertical frequency information 1Byte Refer to the following table
6 Main-screen size information 1Byte As the same contents as item 11 of QST command
7 Color system information 3Byte Refer to the following table
8 Destination information 3Byte CMX (fixed)
9 Check sum 2Byte
10 ETX 1Byte 03hex
At PC signal input At VIDEO signal input
Input signal classification Input Signal Input signal classification Input Signal
– No signal input – No signal input
? OUT OF RANGE ? OUT OF RANGE
A 640 x 400 / 720 x 400 1 SDTV / 525i (480i)
B 640 x 480 2 SDTV / 525p (480p)
C 848 x 480 / 852 x 480 3 SDTV / 625i (576i)
D 800 x 600 4 SDTV / 625p (576p)
E 832 x 624 5 HDTV / 750p (720p)
F 1024 x 768 6 HDTV / 1125i (1035i)
G 1280 x 768 7 HDTV / 1125i (1080i)
H 1152 x 864 8 HDTV / 1125p (1080p)
I 1152 x 870
J 1152 x 900
K 1280 x 960
L 1280 x 1024
M 1400 x 1050
N 1600 x 1200
