Pioneer PDP-436RXE

12
En
Part Names
04
Part Names
Plasma Display
11 ANT (Antenna) input terminal
12 i/o link.A SELECT switch
13 INPUT 1 terminal (SCART)
14 INPUT 2 terminal (SCART)
15 INPUT 3 terminal (SCART)
16 AUDIO OUTPUT terminals (L - R)
17 RS232C terminal (SERVICE ONLY)
18 AC IN terminal
19 HDMI terminal (INPUT 3)
20 INPUT 2 terminals (COMPONENT VIDEO:Y, P B , P R )
Front view
1POWER button
2 POWER ON indicator
3 STANDBY indicator
4 PIC OFF indicator
5 SLEEP indicator
6 INPUT 4 terminals
7 STANDBY/ON button
8INPUT button
9 CHANNEL +/– buttons
10 VOLUME +/– buttons
Press this section (PUSH-OPEN) gently to open the door.
Rear view
*
**
* , and are located in the top
wall of the compartment.
