PDP-502MX, PDP-502MXE
11
1 MAIN POWER ASSY AWZ6405
2 Fuse (10A, FU101) AEK1071
3 VIDEO ASSY
See contrast table (2)
4 YC SEPA. ASSY
See contrast table (2)
NSP 5 Analog Shield Cover ANK1601
6 PCB Spacer AEC1832
NSP 7 Chassis ANA1605
8 Insulating Sheet AMR3199
9 Fan Frame A ANG2330
10 Wire Saddle AEC1745
11 INPUT ASSY AWZ6394
NSP 12 Fan Frame C ANG2332
13 Fan Motor AXM1036
14 Fan Label AAX2746
15 Locking Card Spacer AEC1736
16 VF DD CONVERTER ASSY AWZ6412
17 SENSOR A ASSY AWZ6400
18 FAN CABLE A ASSY AWZ6403
19 FAN CABLE B ASSY AWZ6404
20 Screw BMZ30P060FCU
21 Screw BBZ40P160FZK
22 Spacer Screw AEF1028
23 Wire Barrier AMR3209
24 Nylon Rivet AEC1671
NSP 25 Powder Guard L AMR3201
NSP 26 Powder Guard S AMR3200
27 PCB Mold AMR2115
28 2P Earth Plate ANK1156
29 Fan Cushion AEC1840
30 Screw ABZ30P140FMC
31 Fan Angle Cushion AED1193
32 Screw PPZ50P100FZK
33 PCB Hinge AEC1807
34 Screw AMZ30P060FMC
35 RCC CONTROL A ASSY AWZ6406
36 RCC CONTROL B ASSY AWZ6407
37 RCC CONTROL C ASSY AWZ6408
38 OTL CONTROL A ASSY AWZ6409
39 OTL CONTROL B ASSY AWZ6410
40 OTL CONTROL C ASSY AWZ6411
41 Screw BPZ30P080FZK
42 Hexagon Screw BBA1051
43 Nut ABN1033
Mark No. Description Part No.
(1) EXTERIOR (1/3) SECTION PARTS LIST
Mark No. Description Part No.
3 VIDEO ASSY AWZ6441 AWZ6448
4 YC SEPA. ASSY AWV1776 Not used
(2) CONTRAST TABLE
PDP-502MX/LUCBW and PDP-502MXE/YVLDK are constructed the same except for the following:
Mark
PDP-502MX PDP-502MXE
LUCBW YVLDK
Part No.
Remarks
Symbol and DescriptionNo.
