Pioneer PDP-502MXE Service Manual

PDP-502MX, PDP-502MXE
7
10 Upper Carton AHD3035 AHD3043
15 Operating Instructions ARD1029 Not used
(English/French/Japanese)
15 Operating Instructions Not used ARE1350
(English/French/German/Italian/
Dutch/Spanish)
16 Plasma Caution Sheet ARM1145 Not used
17 Plasma Caution Sheet ARM1147 Not used
19 Caution Sheet ARM1176 Not used
NSP 20 Warranty Card ARY1093 Not used
NSP 21 Warranty Card ARY1102 Not used
NSP 22 Vinyl Pouch AHG–195 Not used
26 AC Power Cord ADG1178 Not used
31 Pin/BNC Conversion Adaptor AKX1052 Not used
40 Plasma Caution Sheet Not used ARM1149
41 EMC Caution Sheet Not used ARM1164
42 EMC Caution Label Not used AAX2708
(1) PACKING PARTS LIST
Mark No. Description Part No.
(2) CONTRAST TABLE
PDP-502MX/LUCBW and PDP-502MXE/YVLDK are constructed the same except for the following:
Mark
PDP-502MX PDP-502MXE
LUCBW YVLDK
Part No.
Remarks
Symbol and DescriptionNo.
1 Under Pad R AHA2239
2 Under Pad L AHA2240
3 Upper Pad R AHA2241
4 Upper Pad L AHA2242
5 Upper Pad C AHA2243
6 Under Pad C AHA2245
7 Front Carton AHB1210
8 Rear Carton AHB1211
9 Code Case AHC1033
10 Upper Carton See contrast table (2)
11 Under Carton AHD3037
12 Mirror Mat AHG1284
13 Polyethirene Sheet AHG1302
14 Protect Sheet SHC-925
15 Operating Instructions See contrast table (2)
16 Plasma Caution Sheet See contrast table (2)
17 Plasma Caution Sheet See contrast table (2)
18 Caution Sheet ARM1168
19 Caution Sheet See contrast table (2)
NSP 20 Warranty Card See contrast table (2)
NSP 21 Warranty Card See contrast table (2)
NSP 22 Vinyl Pouch See contrast table (2)
23 Remote Control Unit AXD1446
(CU-V159)
24 Battery Cover AZN2098
NSP 25 AA (R6/UM-3) Batteries VEM1011
26 AC Power Cord See contrast table (2)
27 Binder Assy AEC1758
28 Cleaning Cloth AED1174
NSP 29 Vinyl Bag (for Screw, Nut) AHG-064
NSP 30 Literature Bag AHG-117
31 Pin/BNC Conversion Adaptor See contrast table (2)
32 Diaplay Stand AMR3168
NSP 33 Stand Bracket ANG2351
34 Screw CPZ30P080FZK
35 Caution Sheet ARM1175
36 Remote Control Unit Case AMR3169
37 Hex Hole Bolt (M8×40) SMZ80H400FZB
38 Washer WAX1F200K320
39 Washer WB80FZB
40 Plasma Caution Sheet See contrast table (2)
41 EMC Caution Sheet See contrast table (2)
42 EMC Caution Label See contrast table (2)
Mark No. Description Part No.
