Pioneer PDP-502MXE Service Manual

PDP-502MX, PDP-502MXE
9
1 Siricon Sheet L AEH1031
2 Siricon Sheet S AEH1030
3 Barrier AMR3166
4 Screw BBZ40P160FZK
5 Rear Case Frame See contrast table (2)
NSP 6 Rear Case See contrast table (2)
7 Stand Bolt ABA1277
8 Screw Collar AEC1848
9 Screw AMZ30P100FZK
10 Hole Rivet AMR2969
11 Solder Warning Label See contrast table (2)
12 Screw Rivet AEC1852
13 Terminal Label D AAX2721
14 Terminal Label F AAX2723
15 Terminal Label G See contrast table (2)
16 Terminal Label A See contrast table (2)
17 Caution Label See contrast table (2)
18 Terminal Label C See contrast table (2)
19 Terminal Label B See contrast table (2)
20 Bolt Caution Label See contrast table (2)
Mark No. Description Part No.
(1) REAR CASE SECTION PARTS LIST
5 Rear Case Frame AMR3147 AMR3170
NSP 6 Rear Case ANE1581 ANE1587
11 Solder Warning Label AAX2644 Not used
15 Terminal Label G AAX2724 Not used
15 Terminal Label E Not used AAX2722
16 Terminal Label A AAX2718 Not used
16 Terminal Label L Not used AAX2734
17 Caution Label ARW1087 Not used
18 Terminal Label C AAX2720 Not used
18 Terminal Label M Not used AAX2735
19 Terminal Label B AAX2719 Not used
20 Bolt Caution Label AAX2727 AAX2728
21 Cleaning Label AAX2751 AAX2766
NSP 22 Name Label AAL2309 AAL2313
NSP 23 UPC Code Label AAX2712 AAX2749
NSP 26 Display Label AAX–359 Not used
28 Barrier Caution Label AAX2759 Not used
29 Connector Cover Not used ANG2355
30 Earth Plate Not used ANK1639
31 Washer Not used ABE1077
32 Terminal Label N Not used AAX2736
(2) CONTRAST TABLE
PDP-502MX/LUCBW and PDP-502MXE/YVLDK are constructed the same except for the following:
Mark
PDP-502MX PDP-502MXE
LUCBW YVLDK
Part No.
Remarks
Symbol and DescriptionNo.
21 Cleaning Label See contrast table (2)
NSP 22 Name Label See contrast table (2)
NSP 23 UPC Code Label See contrast table (2)
NSP 24 Earth Label BAX1014
25 Serial Seal AAX2609
NSP 26 Display Label See contrast table (2)
NSP 27 Label VRW1629
28 Barrier Caution Label See contrast table (2)
29 Connector Cover See contrast table (2)
30 Earth Plate See contrast table (2)
31 Washer See contrast table (2)
32 Terminal Label N See contrast table (2)
Mark No. Description Part No.
