PDP-503CMX, PDP-503MXE, PDA-5002
7
1 Upper Carton See Contrast table (2)
2 Under Carton AHD3037
3 Pad AHA2280
4 Mirror Mat AHG1284
5 Caution Sheet ARM1201
NSP 6 Warranty Card See Contrast table (2)
7 Polyethylene Sheet AHG1302
8 Front Sheet AHB1241
9 Cord Case AHC1037
10 Power Cord See Contrast table (2)
11 Vinyl Bag AHG1310
12 Accessory Case AHC1036
13 • • • • •
14 • • • • •
15 Operating Instructions See Contrast table (2)
(Spanish/Italian/Dutch)
16 CD-ROM AEX1027
(information files)
17 OPerating Instructions See Contrast table (2)
18 Caution Sheet ARM1200
19 Caution Sheet ARM1194
(1) PACKING PARTS LIST
Mark No. Description Part No. Mark No. Description Part No.
20 Plasma Caution Sheet See Contrast table (2)
21 Plasma Caution Sheet See Contrast table (2)
22 Caution Sheet See Contrast table (2)
23 Binder Assy AEC1758
(Speed Clamp × 2, Bead Band × 2)
24 Cleaning Cloth AED1197
(for Wiping Front Panel)
NSP 25 Warranty Card ARY1102
NSP 26 Vinyl Pouch See Contrast table (2)
27 Washer WB80FZB
28 Hex Hole Bolt SMZ80H400FZB
29 Vinyl Bag AHG-064
30 Caution Sheet See Contrast table (2)
31 Remote Control Unit AXD1459
32 Battery Cover AZN2462
NSP 33 Dry Cell Battery (R6P, AA) AEX1026
34 Display Stand AMR3264
35 Remote Control Unit Holder AMR3268
36 Ferrite Core See Contrast table (2)
(2) CONTRAST TABLE
PDP-503CMX/LUCB and PDP-503MXE/YVLDK are constructed the same except for the following :
Mark No. Symbol and Description
Part No.
Remarks
PDP-503CMX PDP-503MXE
LUCB YVLDK
NSP
NSP
1
6
10
15
17
17
20
21
22
26
30
36
Upper Carton
Warranty Card
Power Cord
Operating Instructions (Spanish/Italian/Dutch)
Operating Instructions (Japanese/English/French)
Operating Instructions (English/French/German)
Plasma Caution Sheet
Plasma Caution Sheet
Caution Sheet
Vinyl Pouch
Caution Sheet
Ferrite Core
AHD3094
ARY1093
ADG1178
Not used
ARD1042
Not used
ARM1145
ARM1147
ARM1176
AHG-195
ARM1203
Not used
AHD3097
Not used
Not used
ARC1503
Not used
ARE1360
Not used
ARM1149
Not used
Not used
Not used
ATX1031
To Next Page
