PACKING Parts List
(2) CONTRAST TABLE
PDP-505PE/WYVIXK, PRO-505PU/KUC and PDP-505PE/WYVI are constructed the same except for the following :
Mark
No. Description Part No.
>
1Power Cord See Contrast table (2)
>
2Power Cord See Contrast table (2)
3 Wiping Cloth AED1208
4 Binder Assy AEC1908
5 Code Case See Contrast table (2)
6 Center Pad (50) See Contrast table (2)
NSP 7 Warranty Card See Contrast table (2)
8 Mirror Mat See Contrast table (2)
9Pad See Contrast table (2)
10 Pad See Contrast table (2)
11 Pad See Contrast table (2)
12 Pad See Contrast table (2)
13 Carton (50) See Contrast table (2)
14 Upper Carton See Contrast table (2)
15 Vinyl Bag See Contrast table (2)
16 Caution Card ARM1232
17 Speaker Cushion See Contrast table (2)
18 Vinyl Bag S See Contrast table (2)
19 Ferrite Core See Contrast table (2)
20 Poly Bag See Contrast table (2)
Mark
No. Description Part No.
Mark No. Symbol and Description
PDP-505PE
WYVI
PDP-505PE
WYVIXK
PRO-505PU
KUC
>
1Power Cord ADG1214 ADG1214 Not used
>
2Power Cord Not used Not used ADG1215
5 Code Case AHC1041 AHC1049 Not used
6 Center Pad (50) Not used AHA2335 Not used
NSP 7 Warranty Card ARY1114 ARY1114 ARY1134
8 Mirror Mat AHG1284 AHG1327 AHG1284
9Pad (50T-L) AHA2366 Not used AHA2366
9Pad (T-L) Not used AHA2381 Not used
10 Pad (50T-R) AHA2367 Not used AHA2367
10 Pad (T-R) Not used AHA2382 Not used
11 Pad (50B-L) AHA2368 Not used AHA2368
11 Pad (B-L) Not used AHA2383 Not used
12 Pad (50B-R) AHA2369 Not used AHA2369
12 Pad (B-R) Not used AHA2384 Not used
13 Carton (50) AHD3177 AHD3191 AHD3177
14 Upper Carton (505PE) AHD3265 Not used Not used
14 Upper Carton (50) Not used AHD3271 Not used
14 Upper Carton (50EL) Not used Not used AHD3281
15 Vinyl Bag AHG1340 Not used AHG1340
17 Speaker Cushion AEB1384 AEB1384 Not used
18 Vinyl Bag S AHG1338 Not used AHG1338
19 Ferrite Core ATX1039 ATX1039 Not used
20 Poly Bag Not used AHG1326 Not used
