Pioneer PDP-505PU User Manual

PDP-505PE
71
5678
56
7
8
C
D
F
A
B
E
7.1.9 DISASSEMBLY
PANEL KEY Assy
1
3
∗1
∗1
1
2
1
1
2
2
2
2
2
1
1
2 4
1 1
2
2
2
1 1 1
1
2
1
1
2
2
1
1
2
2
2
2
2
2
2
2
2
5
6
22 2
-1
6
-2
2
1
2
Remove the 25 screws.
4
Remove the screw.
1
Remove the 15 screws.
3
Remove the Rear Case (50P).
5
Remove the flexible cable on the PANEL KEY Assy.
6
Remove the Front Case Assy (50P).
Rear Case (50P) and Front Case Assy (50P)
Front Case Assy (50P)
∗1:
When reassembling, first secure the screws for
these holes to position the Rear Case (50P) correctly.
Note: If you wish to remove only the Front Case Assy, you can
remove it in the order of 1, 4, 5, and 6.
Secure the screws in the order of ~ and Ÿ.
Then secure the screws on the upper side, the sides,
then the lower side.
(Secure this screw first.)
When reassembling the Front Case Assy (50P)
Rear Case (50P)
