Pioneer PDP-506PU User Manual

PDP-506PE
13
5678
56
7
8
C
D
F
A
B
E
(1) FRONT SECTION PARTS LIST
(2) CONTRAST TABLE
PDP-506PE/WYVI and PDP-506PU/KUCXC are constructed the same except for the following:
Mark
No. Description Part No.
1Front Case Assy (506PE) AMB2861
2 Corner Cushion AEB1416
3 Pioneer Name Plate AAM1098
4Power Button AAD4133
5 Coil Spring ABH1120
6 Blind Cushion AEB1415
7 Insulation Sheet A AED1283
8 Insulation Sheet B AED1284
9Power Display Label (506) See Contrast table (2)
10 Screw Rivet AEC1877
Mark No. Symbol and Description PDP-506PE/WYVI PDP-506PU/KUCXC
9Power Display Label (506) AAX3217 Not used

Pioneer PDP-506PU Specifications

General

Brand	Pioneer
Model	PDP-506PU
Category	Monitor
Language	English
