PDP-506PE
37
5678
56
7
8
C
D
F
A
B
E
RESISTORS
R2352 ACN1166
R2304 ACN1174
R2360,R2362 ACN1178
R2277-R2279,R2281 ACN1241
R2210,R2211 RS1/10S151J
R2290 RS1MMF331J
R2222,R2224 RS2MMF5R6J
R2203 RS3LMF821J
Other Resistors RS1/16S###J
OTHERS
KN2350,KN2352 GROUND PLATE ANK-142
KN2354 GROUND PLATE ANK-142
KN2356,KN2357 GROUND PLATE ANK-142
KN2359-KN2363 GROUND PLATE ANK-142
CN2351,CN2352 KR CONNECTOR B4B-PH-K
CN2350 9P TOP POST B9B-EH
[50Y SCAN BLOCK]
SEMICONDUCTORS
IC2403,IC2405,IC2406,IC2408 PS9117
IC2401 PS9851-2(P)
IC2402,IC2407 TC74ACT540FT
COILS AND FILTERS
L2401-L2403 LFEA100J
CAPACITORS
C2404,C2411 ACH1413
C2401,C2407,C2414 CEHAT101M10
C2402,C2403,C2405,C2408-C2410 CKSSYB104K10
C2412 CKSSYB104K10
RESISTORS
R2407,R2421 RAB4C220J
R2402,R2409 RS1/10S0R0J
Other Resistors RS1/16S###J
OTHERS
CN2401 15P BRIDGE CONNECTOR AKM1200
CN2402 15P BRIDGE CONNECTOR AKM1200
[50Y VH D-D CON BLOCK]
SEMICONDUCTORS
IC2531 BA10358F
IC2502 MIP2E3DMC
IC2503 PS2701A-1(L)
IC2534,IC2535 TA76431FR
Q2533 2SC2412K
Q2531 2SC3425
Q2532 2SD2568
Q2511 HN1C01FU
D2534 1SS355
D2522,D2524 CRH01
D2523,D2532 D1FK60
D2533 UDZS33(B)
D2536 UDZS4R7(B)
D2530,D2531 UDZS8R2(B)
COILS AND FILTERS
>T2503 CONVERTER TRANS. ATK1158
L2501 LFEA101J
Mark No. Description Part No.
CAPACITORS
C2531 ACE1177
C2516 ACH1360
C2532 ACH1425
C2513 ACH1428
C2520 CEHAT101M16
C2515 CEHAT101M25
C2528 CEHAT221M16
C2514,C2525,C2534 CKSRYB104K16
C2521,C2533,C2535 CKSRYB104K25
RESISTORS
R2553 RAB4C472J
R2558 RS1/10S0R0J
R2533,R2556 RS1/10S104J
R2534,R2535,R2541 RS1/10S2203F
R2548 RS1/16S1003F
R2550 RS1/16S1802F
R2549,R2557 RS1/16S4702F
R2542,R2545 RS1/16S5601F
VR2503 CCP1390
VR2531 CCP1392
Other Resistors RS1/16S###J
[50Y D-D CON BLOCK]
SEMICONDUCTORS
IC2602 BA10358F
IC2601,IC2603,IC2606 PS2701A-1(L)
IC2605,IC2614 TA76431FR
Q2610 2SA1163
Q2601,Q2609 2SA1576A
Q2608 2SA2005
Q2607 2SC2713
Q2612 2SC4081
Q2605,Q2606 2SD1898
Q2603,Q2604,Q2611 DTC143EUA
Q2602,Q2613,Q2641 HN1C01FU
D2611 1SS226
D2604,D2612 1SS301
D2602,D2613-D2615 1SS355
D2601,D2603,D2609,D2618 CRH01
D2610 D1FL40
D2617 UDZS15(B)
D2607,D2608 UDZS4R7(B)
D2605 UDZS5R1(B)
D2616 UDZS5R6(B)
COILS AND FILTERS
>T2602 CONVERTER TRANS. ATK1156
>T2601 SWITCHING TRANS. ATK1161
CAPACITORS
C2608,C2610 CEHAT101M25
C2613 CEHAT221M25
C2606 CEHAT221M6R3
C2607 CKSRYB102K50
C2605,C2612,C2614 CKSRYB103K50
C2601,C2604,C2609 CKSRYB104K16
C2602,C2615 CKSRYB105K6R3
C2603 CKSRYF104Z50
C2611 CKSSYB104K10
Mark No. Description Part No.
