Command
Name
Function
Effective only in
Factory mode
Remarks
SFR S08
SUS FREQUENCY MODE8 Measures against AM radio noise - Pattern 8 ?
SMM S**
SIDE MASK MODE Setting of the effective area during streaking correction ?
SN0
∗∗∗
SERIAL NO 0 Setting of the serial No. 0 (panel) ?
SN1
∗∗∗
SERIAL NO 1 Setting of the serial No. 1 (panel) ?
SN2
∗∗∗
SERIAL NO 2 Setting of the serial No. 2 (panel) ?
SN3
∗∗∗
SERIAL NO 3 Setting of the serial No. 3 (panel) ?
SN4
∗∗∗
SERIAL NO 4 Setting of the serial No. 4 (panel) ?
SRS
S00
SRS OFF SRS function: off
S01
SRS ON SRS function: on
SYS
S00
SYSTEM CABLE NO Prohibiting monitoring of cable disconnection detection
S01
SYSTEM CABLE YES Permitting monitoring of cable disconnection detection
T
TBS
S00
TRUBASS OFF TruBass function: off
S01
TRUBASS ON TruBass function: on
TRE
∗∗∗
TREBLE ADJUSTMENT Audio treble adjustment
U
UAJ
UN-ADJUSTMENT
Determining the flag for the HD DIGITAL Assy adjustment in "not adjusted" ?
V
VFQ
S01
FREQENCY VIDEO 48Hz Setting the frequency in Mask mode to VD-48 Hz ?
S02
FREQENCY VIDEO 50Hz Setting the frequency in Mask mode to VD-50 Hz ?
S03
FREQENCY VIDEO 60Hz Setting the frequency in Mask mode to VD-60 Hz ?
S05
FREQENCY THEATER 72Hz Setting the frequency in Mask mode to VD-72 Hz ?
S06
FREQENCY 75Hz Setting the frequency in Mask mode to VD-75 Hz ?
S13
FREQENCY PC 60Hz Setting the frequency in Mask mode to PC-60 Hz ?
S14
FREQENCY PC 70Hz Setting the frequency in Mask mode to PC-70 Hz ?
S22
FREQENCY VIDEO 50Hz NONSTD
Setting the frequency in Mask mode to VD-50 Hz (nonstandard) ?
S23
FREQENCY VIDEO 60Hz NONSTD
Setting the frequency in Mask mode to VD-60 Hz (nonstandard) ?
S25
FREQENCY VIDEO 72Hz NONSTD
Setting the frequency in Mask mode to VD-72 Hz (nonstandard) ?
S26
FREQENCY VIDEO 75Hz NONSTD
Setting the frequency in Mask mode to VD-75 Hz (nonstandard) ?
VOF
Vofs ADJUSTMENT Adjustment of the reference value of Vofs voltage ?
VOL
VOLUME Audio volume adjustment
VRP
Vrp ADJUSTMENT Adjustment of the reference value of Vrst-p voltage ?
VSU
Vsus ADJUSTMENT Adjustment of the reference value of Vsus voltage ?
W
WBI S00
WB INITIALIZE NO Panel WB standard output mode: off ?
WBI S01
WB INITIALIZE YES Panel WB standard output mode: on ?
X
XSB
∗∗∗
∗∗∗
∗∗∗
∗∗∗
∗∗∗
X-SUS-B ADJ X-SUS-B ADJ ?
Y
YSB
∗∗∗
Y-SUS-B ADJ Y-SUS-B ADJ ?
YTG
∗∗∗
Y-SUSTAIL ADJ Y-SUSTAIL ADJ ?
YTW
∗∗∗
Y-SUSTAIL W AJD Y-SUSTAIL W AJD ?
