PDP-506PE
67
5678
56
7
8
C
D
F
A
B
E
No.
Submode Name
Adjustable Range Remarks
Submode Items
1 PANEL INFORMATION
2 PANEL WORKS
3 POWER DOWN
4 SHUT DOWN
5 PANEL-1 ADJ (+)
5-1 X-SUS B <=> 120 to 136 Equivalent to XSB
5-2 Y-SUS B <=> 120 to 136 Equivalent to YSB
5-3 Y-SUSTAIL T <=> 120 to 136 Equivalent to YTG
5-4 Y-SUSTAIL W <=> 120 to 136 Equivalent to YTW
5-5 XY-RST W <=> 120 to 136 Equivalent to RSW
5-6 VOL SUS <=> 000 to 255 Equivalent to VSU
5-7 VOL OFFSET <=> 000 to 255 Equivalent to VOF
5-8 VOL RST P <=> 000 to 255 Equivalent to VRP
5-9 SUS FREQ. <=> MODE1 to MODE8 Equivalent to SFR
6 PANEL-2 ADJ (+)
6-1 R-HIGH <=> 000 to 511 Equivalent to PRH
6-2 G-HIGH <=> 000 to 511 Equivalent to PGH
6-3 B-HIGH <=> 000 to 511 Equivalent to PBH
6-4 R-LOW <=> 000 to 999 Equivalent to PRL
6-5 G-LOW <=> 000 to 999 Equivalent to PGL
6-6 B-LOW <=> 000 to 999 Equivalent to PBL
6-7 ABL <=> 000 to 255 Equivalent to ABL
7 PANEL REVISE
7-1 R-LEVEL <=> LV-0 to LV-7 Equivalent to RRL
7-2 G-LEVEL <=> LV-0 to LV-7 Equivalent to RGL
7-3 B-LEVEL <=> LV-0 to LV-7 Equivalent to RBL
8 ETC (+)
8-1 BACKUP DATA <=> NO OPRT<=>TRANSFER or ERR Equivalent to BCP
8-2 DIGITAL EEPROM <=> NO OPRT<=>DELETE/REPAIR Equivalent to FAJ/UAJ
8-3 PD INFO. <=> NO OPRT <=>CLEAR Equivalent to CPD
8-4 SD INFO. <=> NO OPRT <=>CLEAR Equivalent to CSD
8-5 HR-MTR INFO. <=> NO OPRT <=>CLEAR Equivalent to CHM
8-6 PM/B1-B5 <=> NO OPRT <=>CLEAR Equivalent to CPM
8-7 P-COUNT INFO. <=> NO OPRT <=>CLEAR Equivalent to CPC
9 MASK SETUP (+)
9-1 MASK OFF Equivalent to MKS+S00
9-2 SGL MASK 01 <=> Equivalent to MKS+S01
9-3
SGL MASK 02 <=>
<=>V48<=>V50<=>V60<=>P60<=>P70<=>V72<=>V75<=>
(Select each sequence.)
Equivalent to MKS+S02
• • • • • •
9-62 CMB MASK 08 <=> Equivalent to MKC+S08
9-63 CMB MASK 09 <=> Equivalent to MKC+S09
7 Configuration of Panel Factory mode
