Pioneer PDP-507CMX - Page 10

10
RS-232C Adjustment
7
“INTEGRATOR”–“PICTURE” related commands
Command
434CMX
505CMX
Command
425CMX
Command
427CMX
507CMX
Function
Number direct
Last
memory
Comment
Effective Minimum Maximum
VIDEO QUALITY
CNT
++
Adjusts the contrast.

000 255

BRT
++
Adjusts the brightness.

000 255

ENH
++
Adjusts the horizontal enhance.

000 015

ENV
++
Adjusts the vertical enhance.

000 015

COL
++
Adjusts the color.

000 127

TNT
++
Adjusts the tint.

000 060

SHP
++
Adjusts the sharpness.

000 015

WHITE BALANCE
RHI
++
Adjusts R.HIGH of the white balance.

000 255

GHI
++
Adjusts G.HIGH of the white balance.

000 255

BHI
++
Adjusts B.HIGH of the white balance.

000 255

GLW
++
Adjusts G.LOW of the white balance.

000 255

RLW
++
Adjusts R.LOW of the white balance.

000 255

BLW
++
Adjusts B.LOW of the white balance.

000 255

COLOR DETAIL
CGR
++
Adjusts color detail red.

000 060

CGY
++
Adjusts color detail yellow.

000 060

CGG
++
Adjusts color detail green.

000 060

CGC
++
Adjusts color detail cyan.

000 060

CGB
++
Adjusts color detail blue.

000 060

CGM
++
Adjusts color detail magenta.

000 060

GAMMA
GRA
++
Displays the present set value of gradation.
– GRAS18
+
Sets gradation GAMMA 1.8.

– GRAS19
+
Sets gradation GAMMA 1.9.

– GRAS20
+
Sets gradation GAMMA 2.0.

– GRAS21
+
Sets gradation GAMMA 2.1.

– GRAS22
+
Sets gradation GAMMA 2.2.

– GRAS23
+
Sets gradation GAMMA 2.3.

– GRAS24
+
Sets gradation GAMMA 2.4.

PRESET
STD
++
Restores the PICTURE, W/B adjustment value of the integrator
to the initial values.

7
“INTEGRATOR”–“SCREEN” related commands
Command
434CMX
505CMX
Command
425CMX
Command
427CMX
507CMX
Function
Number direct
Last
memory
Comment
Effective Minimum Maximum
POSITION
HPS
++
Adjusts the horizontal position.

000 255

VPS
++
Adjusts the vertical position.

000 255

CLOCK/PHASE
CFR
++
Adjusts the CLOCK (PLL frequency).

000 255

CPH
++
Adjusts the PHASE (PLL phase).

000 031

SIZE
HSI
++
Adjusts the horizontal size.

000 064

VSI
++
Adjusts the vertical size.

000 064

PRESET
FRP
++
Restores the SCREEN adjustment value of the integrator to the
initial values.

7
“INTEGRATOR”–“SETUP” related commands
Command
434CMX
505CMX
Command
425CMX
Command
427CMX
507CMX
Function
Number direct
Last
memory
Comment
Effective Minimum Maximum
SUB VOLUME
SVL
++
Adjusts the SUB VOLUME.

000 020

