Pioneer PDP-6010FD User Manual

PDP-6010FD
10
1
2
3
4
1234
C
D
F
A
B
E
Stand accessory Assy
(AXY1193)
Base cover: ×1
(AXY1198)
Stand pipe (L): ×1
(AXY1186)
Stand pipe (R): ×1
(AXY1187)
Stand accessories
Screw 1 : ×6
(M5 × 10 mm: silver)
Speaker mounting screw : ×10
(M5 × 10 mm: black)
(SBA1269)
Hexagonal wrench : ×1
(Opposite side 4 mm for M5 use)
(SEX1028)
Screw 3 : ×4
(for plastic bands)
(M4 × 10 mm: black)
Screw 2 : ×4
(M6 × 20 mm: black)
Plastic band: ×4
Speaker cable: ×2
(SDS1202)
Bracket Assy (R)
: ×1
(SXG1132)
Bracket Assy (L)
: ×1
(SXG1130)
Bracket Assy (C): ×1
(SXG1131)
Brackets for center
Speaker accessories
Speaker Mounting Fittings
Bracket, for right and left sides
