9.3 DETAILS OF EACH COMMANDS
9.3.1 QS1 (PANEL STATUS)
Model information and version information are returned.
Command
Format
Effective Operation
Modes
Function Remarks
[QS1] Every Time Output of status Return data: 3 (ECO) + 84 (DATA) + 2 (CS) = 89 Byte
2: Panel Generation
6G6
7G7
8 G8
9G9
0 G10
3: Destination
∗
Commonness
A US (Reserved)
E EU (Reserved)
J Japan (Reserved)
4: Grade
∗
Commonness
Z Evaluation
Data Arrangement
Data
Length
Output Example
ECO 3 byte QS1 (Fixed)
1 Resolution/Size 1 byte F
2 Panel Generation 1 byte 8
3 Destination 1 byte
∗
4 Grade 1 byte
∗
5 Panel Product Form 1 byte B
6 Boot version of Module microcomputer 3 byte 05F
7 Program version of Module microcomputer 8 byte -02F
8 Boot version of SQ_LSI 3 byte 04F
9 Program version of SQ_LSI 8 byte -01Y
10 Panel information 8 byte G8_50F
8
A
H
B
010AE
01A
-01A
01A
-01A
01A
FF
11
14
15
Reserved (panel section) 8 byte
∗∗∗∗∗∗∗∗
16
, (comma) 1 byte
17
MTB generation 1 byte
,
18
MTB destination 1 byte
19
MTB grade 1 byte
20
MTB product form 1 byte
21
Program version of IF microcomputer 8 byte
22
Boot version of IF microcomputer 4 byte
Program version of Main microcomputer 8 byte
23
Boot version of Main microcomputer 4 byte
24
Program version of ASIC 8 byte
25
Boot version of ASIC 4 byte
CS (Check Sum)
2 byte
5: Panel Product Form
S System model
B All-in-one design TV
M Monitor
D Standard module
E Simple module
15: MTB Generation
6
G6
7
G7
8
G8
9
G9
0
G10
16: MTB Destination
A North America
C China
E Europe
G General
J Japan
U Australia
17: MTB Grade
H Elite/XDA/Step-upD
T Step-upA/XG/XC/Regular (US)
B Not used
18: MTB Product Form
S System model
B One body model
S RegularD
R RegularA
1: Resolution/Size
3
1024∗768/42
4
1024∗768/43
5
1280∗768/50
6
1365∗768/50
7
1365∗768/60
E
1920∗1080/42
F
1920∗1080/50
G
1920∗1080/60
10: Panel Information
1 to 3rd byte G8_
42
50
60
∗
Generation information G8 + _(under bar) fixed
4 to 5th byte 42 inch
50 inch
60 inch
PSIZE information and SQ_LSI version
mismatching (version mismatching at SD)
F
X
∗
_
6th byte FHD model
XGA model
Model information and SQ_LSI version
mismatching (version mismatching at SD)
7th byte Under bar
6
4
∗
‘
8th byte 2nd PLANT (XGA 50 inch only)
1st PLANT (XGA 50 inch only)
PLANT information and SQ_LSI version
mismatching (version mismatching at SD)
Others
