Pioneer SC-LX75 Service Manual

2
SC-LX85
1
2 3 4
A
B
C
D
E
F
1
2 3 4
1. CONTRAST OF MISCELLANEOUS PARTS
CONTRAST TABLE
SC-57/UXJCB, SC-LX85/SYXJ5 and SC-LX75/SYXJ5 are constructed the same except for the following:
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions, apply as you think it appropriate.)
Nos. indicate the pages and Nos. in the service manual for the base model.
NOTES:
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
5
6 1
4 7 3
R 5 0
1
R 0
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 10
3
R50
1R0
561
473
RN1/4PC F562 x 10
1
5621 5 26 1
Mark No. Symbol and Description SC-57/UXJCB SC-LX85/SYXJ5 SC-LX75/SYXJ5 Remarks
PCB ASSEMBLIES
P85-1 1..IR POWER AMP ASSY AWH7030 AWH7037 AWH7040
NSP 1..IR BUFFER ASSY AWM8249 AWM8282 AWM8282
P85-2 2..IR BUFFER ASSY AWX9793 AWX9952 AWX9952
NSP 1..PRIM DISPLAY ASSY AWM8250 AWM8262 AWM8262
P85-4 2..PRIMARY ASSY AWX9799 AWX9848 AWX9848
P87-1 2..DISPLAY ASSY AWX9796 AWX9967 AWX9967
P87-4 2..MIC HP ASSY AWX9800 AWX9968 AWX9968
NSP 1..AUDIO COMPOSITE ASSY AWR7106 AWR7107 AWR7113
P83-2 2..AUDIO ASSY AWX9790 AWX9831 AWX9834
P83-3 2..COMPOSITE ASSY AWX9791 AWX9791 AWX9836
NSP 1..INTERFACE REG ASSY AWR7111 AWR7124 AWR7124
P81-3 2..IR REG ASSY AWX9806 AWX9954 AWX9954
P81-4 2..B DIODE ASSY AWX9808 AWX9958 AWX9958
P85-7 2..A REG BRIDGE ASSY AWX9810 AWX9970 AWX9970
NSP 1..REG BRIDGE ASSY AWR7112 AWR7115 AWR7125
P81-6 2..DISPLAY BRIDGE ASSY AWX9815 AWX9956 AWX9956
P81-7 2..F-IN BRIDGE ASSY AWX9816 AWX9965 AWX9965
P83-9 2..MCH BRIDGE ASSY AWX9818 AWX9818 Not used
P83-11 2..MULTI CH IN ASSY AWX9857 AWX9856 Not used
P85-8 2..REG ASSY AWX9813 AWX9955 AWX9955
P85-10 2..FB-CONNECT ASSY AWX9819 AWX9966 AWX9966
P87-6 1..FRONT HDMI USB ASSY AWX9749 AWX9969 AWX9969
P83-13 1..DAC HIGH ASSY AWX9822 AWX9858 AWX9861
P83-14 1..DIGITAL MAIN ASSY AWX9827 AWX9727 AWX9950
P83-15 1..COMPONENT ASSY AWX9866 AWX9951 AWX9867
PACKING SECTION
> P79-2 AC Power Cord ADG7111 ADG7062 ADG7062
P79-6 Packing Case AHD8722 AHD8723 AHD8730
P79-9 Operating Instructions (En) ARB7459 Not used Not used
P79-12 Operating Instructions (CD-ROM) ARU7006 ARU7004 ARU7028
NSP P79-13 Warranty Card ARY7007 ARY7128 ARY7128
P79-14 Remote Control Unit SEL/MID AXD7612 Not used AXD7613
P79-14 RF Remote Control Unit Not used AXD7580 Not used

Pioneer SC-LX75 Specifications

General

Brand	Pioneer
Model	SC-LX75
Category	Receiver
Language	English
