Pioneer SC-LX75 Service Manual

3
SC-LX85
5
6 7 8
5
6 7 8
A
B
C
D
E
F
Notes : For PCB ASSEMBLIES, Refer to “CONTRAST OF PCB ASSEMBLIES”.
When a Wifi converter is defective, please replace with a product stock of AS-WL300.
When a Wifi cable is defective or broken, please replace to ADE7138 which has clamp filter attached for this model.
P79-15 Battery Door AZN8047 Not used AZN8047
P79-15 Battery Cover Not used AZN8049 Not used
NSP P79-17 Dry Cell Battery (R3) VEM1051 Not used VEM1051
NSP P79-17 Dry Cell Battery (LR6) Not used VEM1053 Not used
Operating Instructions Not used ARH7107 ARH7107
Operating Instructions Not used ARH7108 ARH7108
Operating Instructions Not used ARH7109 ARH7109
NSP Label (WEEE) Not used ARW7322 Not used
NSP Name Label AD(EL) Not used AAL7447 Not used
NSP Name Label RC(EL) Not used AAL7446 Not used
IR Bluster Cable Not used ADF7007 Not used
RF Receiver Box Not used AXX7272 Not used
RF Remote Caution Not used ARM7131 Not used
Manual Assy Not used AXX7286 AXX7286
Wifi Cable (service) Not used ADE7138 ADE7138
NSP
Wifi Converter E Not used
• • • • • • • • • • • •
EXTERIOR SECTION
P81-9 Power Transformer (T1501) ATS7447 ATS7448 ATS7439
> P81-10 Fuse (FU13, FU14 : 1 A) REK1142 Not used Not used
>
P81-10 Fuse (FU13, FU14 : T800mA) Not used AEK7072 AEK7072
> P81-11 Fuse (FU11, FU12, FU15 : 1.25 A) REK1143 Not used Not used
>
P81-11 Fuse (FU11, FU12, FU15 : T1 A) Not used AEK7073 AEK7073
> P81-12 Fuse (FU10 : 4 A) REK1149 Not used Not used
>
P81-12 Fuse (FU10 : T3.15 A) Not used AEK1059 AEK1059
P81-24 Insulator AMR7198 DXA1904 DXA1904
REAR SECTION
P83-16 AM/FM Tuner Unit AXX7282 AXX7283 AXX7283
P83-23 Rear Panel ANC8599 ANC8600 ANC8607
P83-25 D. Main Shield 85 (MTL) ANK7162
ANK7162
Not used
NSP P83-26 PC Support VEC1749
VEC1749 Not used
P83-36 Nylon Rivet AEC7406
AEC7406
Not used
CHASSIS SECTION
> P85-13 Fuse (FU4 : 2 A) REK1139 Not used Not used
> P85-13 Fuse (FU4 : T4 A) Not used REK1104 REK1104
>
P85-14 Fuse (FU21, FU22, FU31, FU32 : 1.25A) REK1143 Not used Not used
>
P85-14 Fuse (FU21, FU22 : T800 mA) Not used AEK7072 AEK7072
>
P85-14 Fuse (FU31, FU32 : T1 A) Not used AEK7073 AEK7073
> P85-15 Fuse (FU1 : 10 A) REK1154 Not used Not used
>
P85-15 Fuse (FU1 : T5 A) Not used AEK1061 AEK1061
FRONT SECTION
P87-13 Filter AAK8443 AAK8459 AAK8459
P87-14 Display Panel AAK8567 AAK8568 AAK8568
NSP P87-23 Panel Base AMB8041 AMB8042 AMB8042
P87-26 Door Panel ANB7562 ANB7563 ANB7563
P87-27 Front Panel (AL) ANB7565 ANB7566 ANB7570
P87-29 PIONEER Badge (AL) VAM1159 VAM1158 VAM1158
Mark No. Symbol and Description SC-57/UXJCB SC-LX85/SYXJ5 SC-LX75/SYXJ5 Remarks

Pioneer SC-LX75 Specifications

General

Brand	Pioneer
Model	SC-LX75
Category	Receiver
Language	English
