Pioneer SC-LX75 Service Manual

5
SC-LX85
5
6 7 8
5
6 7 8
A
B
C
D
E
F
E
F MULTI CH IN ASSY
AWX9857 and AWX9856 are constructed the same except for the following:
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
F
F DIGITAL MAIN ASSY
AWX9827, AWX9727 and AWX9950 are constructed the same except for the following:
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
Mark Symbol and Description AWX9857 AWX9856 Remarks
C7761-C7764, C7767-C7770 Not used CCSRCH101J50
C7773-C7776, C7779-C7782 Not used CCSRCH101J50
Mark Symbol and Description AWX9827 AWX9727 AWX9950 Remarks
R610, R618 Not used RS1/8SQ105J RS1/8SQ105J
R9513 RS1/16SS100J RS1/16SS0R0J RS1/16SS100J
R9518 RS1/16SS82R0D RS1/16SS82R0D RS1/16SS1501D
R9519 RS1/16SS331J RS1/16SS331J RS1/16SS152J
R9520 RS1/16SS7501D RS1/16SS7501D RS1/16SS3302D
R9521 RS1/16SS622J RS1/16SS622J RS1/16SS163J
R9522 RS1/16SS3301D RS1/16SS3301D RS1/16SS1502D
R9531 RS1/16SS3302D RS1/16SS9101D RS1/16SS3302D
R9532 RS1/16SS123J RS1/16SS562J RS1/16SS123J
R9533 RS1/16SS2402D RS1/16SS6801D RS1/16SS2402D
R9534 RS1/16SS2401D RS1/16SS4700D RS1/16SS2401D
R9535 RS1/16SS112J RS1/16SS301J RS1/16SS112J
R9536, R9540, R9542, R9543 RS1/8SQ0R0J Not used RS1/8SQ0R0J
R9555, R9564 RS1/8SQ0R0J Not used RS1/8SQ0R0J
C9577 Not used ACH7309 Not used
C9578 Not used ACH7314 Not used
C140, C995, C1355 VCH1277 VCH1277 CEVW221M4
C197 Not used CCSSCH101J50 CCSSCH101J50
C203, C428, C447 CKSSYB104K16 CCSSCH331J50 CCSSCH331J50
C619, C650 CCSSCH102J50 CCSSCH101J50 CCSSCH101J50
C996, C1672, C1673 ACH7306 ACH7306 Not used
C1008 CCSSCH471J50 CCSSCH101J50 CCSSCH101J50
C1770, C1847 CEVW101M16 CEVW101M16 Not used
C9056, C9072 CCSSCH471J50 CCSSCH101J50 CCSSCH101J50
C9314 CKSSYB104K16 CCSSCH180J50 CCSSCH180J50
C9322 Not used CCSSCH220J50 CCSSCH220J50
C9547 CKSSYB682K25 CKSSYB682K25 CCSSCH102J50
C9553 CKSSYB472K50 CKSSYB472K50 CCSSCH102J50
C9565 CKSSYB152K50 CKSSYB472K50 CKSSYB152K50
C9570 CCSSCH102J50 CKSSYB682K25 CCSSCH102J50
C9588, C9608 CFHXSQ103J16 CFHXSQ103J16 Not used
C9593 ACH7306 ACH7306 Not used
C9621 CCSSCH101J50 CKSSYB104K16 CCSSCH101J50
C9742 CCSSCH221J50 CCSSCH101J50 CCSSCH101J50
C9751 CCSSCH471J50 CCSSCH101J50 CCSSCH101J50
C9757 CKSSYB104K16 CCSSCH101J50 CCSSCH101J50
C1836 CEVW470M16 CEVW470M16 Not used
C156 VCH1268 VCH1268 CEVW101M4
C1031, C9004, C9702 VCH1234 VCH1234 CEVW101M16
C9537 VCH1234 VCH1234 Not used
