Pioneer SC-LX75 Service Manual

6
SC-LX85
1
2 3 4
A
B
C
D
E
F
1
2 3 4
H
F COMPONENT ASSY
AWX9866, AWX9951 and AWX9867 are constructed the same except for the following:
I
F COMPOSITE ASSY
AWX9791 and AWX9836 are constructed the same except for the following:
J
F MIC HP ASSY
AWX9800 and AWX9968 are constructed the same except for the following:
K
F DISPLAY ASSY
AWX9796 and AWX9967 are constructed the same except for the following:
O
F IR BUFFER ASSY
AWX9793 and AWX9952 are constructed the same except for the following:
R
F IR POWER AMP ASSY
AWH7030, AWH7037 and AWH7040 are constructed the same except for the following:
Mark Symbol and Description AWX9866 AWX9951 AWX9867 Remarks
JA8301 6P PIN JACK AU AKB7225 AKB7225 AKB7224
JA8302, JA8304 3P PIN JACK AU AKB7228 AKB7228 AKB7227
JA8305 3P PIN JACK AU AKB7228 AKB7228 Not used
R8316, R8318, R8320 RS1/10SR68R0F RS1/10SR68R0F Not used
R8317, R8319, R8321 RS1/10SR3R9J RS1/10SR3R9J Not used
R8361, R8362 RS1/10SR0R0J RS1/10SR100J RS1/10SR100J
C8394 CCSRCH470J50 CCSRCH470J50 Not used
Mark Symbol and Description AWX9791 AWX9836 Remarks
JA3601-JA3603 2P PIN JACK AKB7230 AKB7229
JA3604, JA3605 1P PIN JACK AKB7232 AKB7231
R3616 RS1/10SR68R0D RS1/10SR68R0F
C3608, C3610 CKSRYB104K16 CKSRYB104K50
Mark Symbol and Description AWX9800 AWX9968 Remarks
C3473 CKSRYB471K50 CCSRCH471J50
C3490 CKSRYB102K50 CCSRCH102J50
Mark Symbol and Description AWX9796 AWX9967 Remarks
C3006, C3302 CKSRYB471K50 CCSRCH471J50
C3102, C3201, C3306 CKSRYB102K50 CCSRCH102J50
C3104 CKSRYB102K50 CCSRCH330J50
Mark Symbol and Description AWX9793 AWX9952 Remarks
R6857 RS1/8SQ225J RS1/8SQ224J
Mark Symbol and Description AWH7030 AWH7037 AWH7040 Remarks
IC4004 TC74VHC08FK TC74VHCT08AFKS1 TC74VHCT08AFKS1
IC4905 TC7SH08FUS1 TC7SET08FUS1 TC7SET08FUS1
IC5101 UPC4570G2-A Not used Not used
Q4121, Q4221, Q4721 2SC2713 Not used Not used
Q4111, Q4211, Q4311, Q4411 LSA1576UB LTA114TUB LTA114TUB
Q4511, Q4611, Q4711, Q4811 LSA1576UB LTA114TUB LTA114TUB
Q4911 LSA1576UB LTA114TUB LTA114TUB
Q4122, Q4222, Q4722 LSA1576UB Not used Not used
Q4023, Q4025 LSC4081UB DTC623TU DTC623TU
Q5101 LSC4081UB Not used Not used
Q4105, Q4106, Q4205, Q4206 LTC124EUB DTC115EUA DTC115EUA
Q4305, Q4306, Q4405, Q4406 LTC124EUB DTC115EUA DTC115EUA
Q4505, Q4506, Q4605, Q4606 LTC124EUB DTC115EUA DTC115EUA
Q4705, Q4706, Q4805, Q4806 LTC124EUB DTC115EUA DTC115EUA
