Pioneer SC-LX75 Service Manual

8
SC-LX85
1
2 3 4
A
B
C
D
E
F
1
2 3 4
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
S
F PRIMARY ASSY
AWX9799 and AWX9848 are constructed the same except for the following:
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
R4096, R4110, R4210, R4310 RS1/10SR472J RS1/10SR103J RS1/10SR103J
R4410, R4510, R4610, R4710 RS1/10SR472J RS1/10SR103J RS1/10SR103J
R4810, R4910 RS1/10SR472J RS1/10SR103J RS1/10SR103J
R5101, R5102 RS1/10SR473J Not used Not used
R5111, R5120, R5129 RS1/10SR4R7J Not used Not used
R5000 RS1/10SR5600F RS1/10SR1501F RS1/10SR1501F
R5103 RS1/10SR682J Not used Not used
R5135 RS1/10SR821J Not used Not used
R5035, R5037 RS1/8SQ0R0J Not used Not used
R5029, R5030 RS1/8SQ0R0J RS1/8SQ103J RS1/8SQ103J
R5012, R5013, R5020, R5021 RS1/8SQ103J RS1/8SQ104J RS1/8SQ104J
R5011 RS1/8SQ103J RS1/8SQ473J RS1/8SQ473J
R5019 RS1/8SQ104J RS1/8SQ224J RS1/8SQ224J
R5018 RS1/8SQ104J RS1/8SQ474J RS1/8SQ474J
R5083-R5087 RS1/8SQ105J Not used Not used
R5014, R5022 RS1/8SQ223J RS1/8SQ683J RS1/8SQ683J
R5016, R5024 RS1/8SQ473J RS1/8SQ104J RS1/8SQ104J
C4186, C4286, C4786 CCSRCH100D50 Not used Not used
C4012 CCSRCH331J50 CCSRCH221J50 CCSRCH221J50
C4045, C4049, C5001-C5005 CCSRCH331J50 Not used Not used
C4184, C4284, C4784 CCSRCH471J50 Not used Not used
C4121, C4122, C4221, C4222 CFHXSQ103J16 CFHXSQ472J16 CFHXSQ472J16
C4321, C4322, C4421, C4422 CFHXSQ103J16 CFHXSQ472J16 CFHXSQ472J16
C4521, C4522, C4621, C4622 CFHXSQ103J16 CFHXSQ472J16 CFHXSQ472J16
C4721, C4722, C4821, C4822 CFHXSQ103J16 CFHXSQ472J16 CFHXSQ472J16
C4921, C4922 CFHXSQ103J16 CFHXSQ472J16 CFHXSQ472J16
C5102, C5103 CFHXSQ103J16 Not used Not used
C4151, C4251, C4351, C4451 CKSRYB103K50 Not used Not used
C4551, C4651, C4751, C4851 CKSRYB103K50 Not used Not used
C4951 CKSRYB103K50 Not used Not used
C4258, C4458, C4658, C4758 CKSRYB104K50 CKSRYB103K50 CKSRYB103K50
C4858 CKSRYB104K50 CKSRYB103K50 CKSRYB103K50
C4006, C4124, C4152, C4153 CKSRYB104K50 Not used Not used
C4224, C4252, C4253, C4324 CKSRYB104K50 Not used Not used
C4352, C4353, C4424, C4452 CKSRYB104K50 Not used Not used
C4453, C4524, C4552, C4553 CKSRYB104K50 Not used Not used
C4624, C4652, C4653, C4724 CKSRYB104K50 Not used Not used
C4752, C4753, C4824, C4852 CKSRYB104K50 Not used Not used
C4853, C4924, C4952, C4953 CKSRYB104K50 Not used Not used
C5101 CKSRYB104K50 Not used Not used
C5106 CKSRYB224K25 Not used Not used
C4083, C4084 Not used ACE7082 ACE7082
Mark Symbol and Description AWH7030 AWH7037 AWH7040 Remarks
Mark Symbol and Description AWX9799 AWX9848 Remarks
L1 LINE FILTER ATF7046 ATF7050
CN81 CONNECTOR B2P3-VH Not used
CN82 CONNECTOR(VH) Not used B3P5-VH
VA1 VARISTOR Not used TND10V-511KB00AAA0
C81 ACE7013 Not used
