SC-LX85
5
6 7 8
5
6 7 8
A
B
C
D
E
F
U
F
REG ASSY
Although AWX9813 and AWX9955 are different in part number, they consist of the same service components.
V
F
IR REG ASSY
AWX9806 and AWX9954 are constructed the same except for the following:
W
F
B DIODE ASSY
AWX9808 and AWX9958 are constructed the same except for the following:
Y
F
FB-CONNECT ASSY
AWX9819 and AWX9966 are constructed the same except for the following:
e
F
DISPLAY BRIDGE ASSY
AWX9815 and AWX9956 are constructed the same except for the following:
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
f
F
F-IN BRIDGE ASSY
AWX9816 and AWX9965 are constructed the same except for the following:
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
h
F
A REG BRIDGE ASSY
AWX9810 and AWX9970 are constructed the same except for the following:
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
Mark Symbol and Description AWX9806 AWX9954 Remarks
R7258 RS1/4SA822J RS1/4SA105J
Mark Symbol and Description AWX9808 AWX9958 Remarks
R7400 RS1/4SA823J RS1/4SA913J
R7401 RS1/4SA823J RS1/4SA683J
Mark Symbol and Description AWX9819 AWX9966 Remarks
C7693, C7696 CCSRCH270J50 Not used
C7694, C7697 CCSRCH331J50 Not used
Mark Symbol and Description AWX9815 AWX9956 Remarks
C7654 Not used CCSRCH101J50
C7901, C7905 Not used CCSRCH100D50
Mark Symbol and Description AWX9816 AWX9965 Remarks
R7161 RS1/10SR0R0J RS1/10SR100J
R7669 Not used RS1/10SR105J
C7168 Not used CCSRCH101J50
C7171 Not used CCSRCH330J50
Mark Symbol and Description AWX9810 AWX9970 Remarks
R5777, R5780 Not used RS1/10SR472J
