Frequency and Tuning| frequency response | 20Hz to 50kHz |
|---|---|
| frequency range FM | 87-108 MHz |
| frequency range AM | 525-1605 kHz |
Audio Specifications| harmonic distortion | less than 0.5% at 1kHz rated output |
|---|---|
| hum and noise tape head | better than 75dB |
| hum and noise mag | better than 80dB |
Inputs and Outputs| input impedance magnetic phono | 2.4mV, 50k ohms |
|---|---|
| input impedance ceramic phono | 51mV, 90k ohms |
| input impedance tape head | 1.5mV, 120k ohms |
Power| power requirements | 110V, 117V, 130V, 220V, 240V switchable |
|---|---|
| power consumption | 285VA, 255W max |
| power output per channel | 50 watts per channel |
Weight and Dimensions| width | 405 mm |
|---|---|
| height | 137 mm |
| depth | 350 mm |
| weight without package | 10.6 kg |
| weight with package | 13.3 kg |
