VSA-E08
6
AWX7709 and AWX7705 are constructed the same except for the following :
MAIN CONTROL ASSY
F
D
Mark Symbol and Description
Part No.
Remarks
AWX7705 AWX7709
IC102 BU4052BCF Not used
IC103, IC105 NJM4558MD UPC4570G2
IC109 NJM4558MD Not used
IC110 M62429FP Not used
IC115 Not used NJM4558LD
IC901 PD5589A PD5596A
Q113, Q114 2SC2878 Not used
Q991 2SC1740S Not used
D201, D202 UDZS5.1B Not used
D251, D252 Not used 1SS355
D253 Not used UDZS5.1B
D991 1SS355 Not used
D995 UDZ11B Not used
C101- C110 Not used CCSQCH221J50
C131, C132, C253, C254 Not used CKSQYB103K50
C141, C142, C145- C150 CEAT100M50 Not used
C143, C144 CKSQYB103K50 Not used
C155, C156, C165, C166, C175, C176 Not used CCSQCH101J50
C183- C188 Not used CCSQCH221J50
C252 Not used CEAT470M16
C960, C961 CCSQCH101J50 Not used
C991 CEAT101M16 Not used
C992 CKSQYF225Z16 Not used
R109 RD1/2VM391J Not used
R110 RS1/10S472J Not used
R129, R130 RS1/10S104J Not used
R131, R132, R991 RS1/10S471J Not used
R133, R134, R141, R142, R928, R934- R936 RS1/10S102J Not used
R975- R978, R980- R983, R986, R987 RS1/10S102J Not used
R143, R144 RS1/10S102J RS1/10S331J
R135, R136, R925 RS1/10S103J Not used
R145, R146 RS1/10S473J Not used
R207- R211, R252, R253 Not used RS1/10S104J
R251 Not used RS1/10S474J
R254 Not used RS1/10S102J
R325- R330, R333, R334 RS1/10S0R0J Not used
R370 Not used RS1/10S0R0J
R926, R927 Not used RS1/10S103J
CN902 13P FFC CONNECTOR HLEM13R-1 Not used
NSP J101 Not used DB916NS0
J102 Not used DB216NS0
AWX7470 and AWX7366 are constructed the same except for the following :
TRANS 2-2 ASSY
F
O
Mark Symbol and Description
Part No.
Remarks
AWX7366 AWX7470
IC5501 AEK7018 (4A) AEK7019 (5A)
C5501, C5502 Not used ACH1237 (1µF/100V)
R5501 Not used RFA1/4PS220J
To Next Page
