VSA-E08
7
AWX7559 and AWX7310 are constructed the same except for the following :
REGULATOR ASSY
F
M
Mark Symbol and Description
Part No.
Remarks
AWX7310 AWX7559
IC5003 NJM78M12FA Not used
D5009 D3SBA20(B) LN4SB60-4003
C5007 CEAT472M16 CEAT103M16
C5012 CKCYF103Z50 Not used
C5013 CEAT101M25 Not used
C5019, C5021, C5023 CEAT101M10 CEAT221M10
C5029 Not used CEAT221M50
C5030 (1µF/100V) Not used ACH1237
AWX7701 and AWX7698 are constructed the same except for the following :
DISPLAY ASSY
F
S
Mark Symbol and Description
Part No.
Remarks
AWX7698 AWX7701
IC7051 TC7W53FU Not used
Q7002 DTC124EK Not used
Q7053 FMA1A Not used
Q7054 DTC124EK Not used
D7002 SLR-343DC(NPQ) Not used
D7054– D7057 1SS355 Not used
S7022, S7024–S7028, S7030 VSG1009 Not used
C7053 CKSQYB153K50 Not used
C7091 CKSQYB102K50 Not used
R7038 RS1/10S271J Not used
R7047, R7048, R7056 RS1/10S223J Not used
R7057, R7061 RS1/10S103J Not used
R7058 RS1/10S392J Not used
R7411, R7413, R7414, R7416, R7417 Not used RS1/10S0R0J
VIDEO ASSY
F
P
Mark Symbol and Description
Part No.
Remarks
AWX7307 AWX7676
IC731 NJM2279M Not used
D731 1SS355 Not used
C732, C733, C736, CKSQYB473K50 Not used
C791 CKSQYB103K50 Not used
R717 RS1/10S101J RS1/10S0R0J
R732- R735 RS1/10S102J Not used
CN701 52045-2645 HLEM26S-1
CN702 52045-2145 HLEM21S-1
JA705 AKN7014 Not used
AWX7676 and AWX7307 are constructed the same except for the following :
To Next Page
