Pioneer VSA-E08 Service Manual

VSA-E08
8
C6002, C6003 ACG7020 AEC7014 AEC7014
C6006 CEAT470M25 CEAT221M25 CEAT221M25
R6001 RCN1080 Not used Not used
R6002 Not used RD1/4PU1R0J RD1/4PU1R0J
L6003, L6004 Not used ATX1012 ATX1012
J6000 Not used D20PYY0335E D20PYY0335E
T6001 ATT7043 ATT7040 ATT7040
RY6001 ASR7022 ASR1044 ASR1044
Y6003 AWG18 BOARD IN
Not used ADX7321 Not used
Y6004 AWG18 BOARD IN Not used ADX7320 Not used
Y6005 AWG18 BOARD IN Not used ADX7319 Not used
6004 AKP1053 Not used Not used
6001 Not used 51048-0300 51048-0300
AWX7690 and AWX7658 are constructed the same except for the following :
SP / PS ASSY
F
L
Mark Symbol and Description
Part No.
Remarks
AWX7658 AWX7690
IC3001 Not used AEK7007
Q3501 Not used 2SC4793
Q3502- Q3505 Not used DTC124ES
Q3506 Not used 2SA992
D3052, D3054, D3056, D3058, D3060 Not used 1SS133
D3503, D3504, D3509 Not used 1SS133
D3501, D3502 Not used S5688G
D3505 Not used MTZJ16B
D3507 Not used MTZJ5.1B
D3508 Not used MTZJ11B
C3101- C3105 CFTYA104J50 CFTYA224J50
C3106- C3110 Not used CFTYA224J50
C3111- C3117 CQHA102J2A CQMA332K2E
C3501 Not used CEAT471M35
C3502 Not used CEAT1R0M50
C3503 Not used CKCYF103Z50
C3504 Not used CEAT471M25
C3505 Not used CEAT101M16
C3506 Not used CCCCH680J50
R3133, R3134 Not used RS1LMF471J
R3501 Not used RD1/4PU820J
R3502, R3506, R3507 Not used RD1/4PU473J
R3503 Not used RD1/4PU102J
R3504 Not used RD1/4PU104J
R3505 Not used RD1/4PU682J
R3508 Not used RD1/4PU103J
CN3002 Not used KM250MA3
CN3101 AKE7058 AKE7059
CN3102 AKE7060 AKE7061
Mark
Symbol and Description
Part No.
AWX7311 AWX7345 AWX7454
Remarks
PRIMARY ASSY
AWX7311, AWX7345 and AWX7454 are constructed the same except for the following:
F
V
