Pioneer XR-A330 Service Manual

XR-A660, XR-A330
31
A
B
C
D
5
678
5
6
7
8
10000pF/AC250V
XR-A660/KUCXJ : REK1083 (5A)
XR-A660/YPWXJ : AEK1057 (T2A)
XR-A330/KUCXJ : REK1082(4A)
XR-A330/YPWXJ : AEK1056 (T1.6A)
KUCXJ : AKP7032
YPWXJ : BKP1046
KUCXJ ONLY
KUCXJ ONLY
• NOTE FOR FUSE REPLACEMENT
FOR CONTINUED PROTECTION AGAINST RISK OF FIRE.
REPLACE WITH SAME TYPE AND RATINGS ONLY.
CAUTION -
YPWXJ ONLY
