Pioneer XR-A330 Service Manual

47
XR-A660, XR-A330
Mark No. Description Part No.
Mark No. Description Part No.
(2) PARTS LIST FOR XWZ3141
SEMICONDUCTORS
IC8201 BA5923FP
IC8101 LA9241ML
IC8301 LC78622NE
Q8101 2SA1048
Q8251, Q8252 2SB1237X
Q8253, Q8254 2SD1858X
D8253 1SS181
D8251, D8252 1SS355
COILS AND FILTERS
L8351, L8352 LFA1R0K
L8201, L8371 LFA470J
CAPACITORS
C8145, C8352, C8354, C8356, C8358 CCSQCH101J50
C8361, C8362 CCSQCH101J50
C8132, C8311 CCSQCH150J50
C8310 CCSQCH180J50
C8131 CCSQCH300J50
C8129 CCSQCK1R0C50
C8142 CEAL101M6R3
C8127 CEAL1R0M50
C8126, C8139 CEAL470M16
C8135 CEAL4R7M16
C8124 CEALR47M50
C8136 CEAT100M50
C8108, C8306, C8371 CEAT101M10
C8202 CEAT101M25
C8101 CEAT3R3M50
C8105 CEAT470M16
C8109 CEATR22M50
C8106, C8119, C8133, C8307, C8308 CKSQYB102K50
C8360 CKSQYB102K50
C8102, C8122, C8123, C8130 CKSQYB103K50
C8137, C8138, C8201, C8309, C8312 CKSQYB103K50
C8134, C8302, C8303 CKSQYB104K25
C8353, C8359 CKSQYB152K50
C8111 CKSQYB153K25
C8114, C8117, C8120, C8121 CKSQYB154K16
C8125 CKSQYB221K50
C8107 CKSQYB223K50
C8110 CKSQYB331K50
C8115, C8128 CKSQYB332K50
C8113 CKSQYB333K25
C8112, C8141 CKSQYB334K16
C8116, C8140, C8355, C8357 CKSQYB473K50
C8118, C8255–C8257, C8301 CKSQYF104Z25
C8304, C8305 CKSQYF104Z25
RESISTORS
All Resistors RS1/10S J
OTHERS
CN8003 6P JUMPER CONNECTOR 52151-0610
CN8002 KR CONNECTOR B6B-PH-K-S
CN8005 3P SIDE POST BS3P-SHF-1AA
CN8004 FFC CONNECTOR 20P HLEM22R-1
CN8001 FFC CONNECTOR SLW15S-1C7
X8301 CERAMIC RESONATOR PSS1008
(16.9344MHz)
C6413 CCSQRH180J50
C6414 CCSQRH8R0D50
C6405 CCSQTH150J50
C6234, C6235 CEAL1R0M50
C6245 CEAL470M16
C6224 CEAT100M50
C6243 CEAT101M16
C6231 CEAT1R0M50
C6227 CEAT220M25
C6214, C6236 CEAT2R2M50
C6262 CEAT3R3M50
C6219 CEAT470M10
C6244 CEAT470M16
C6249, C6250, C6265, C6266 CEAT4R7M50
C6258 CEJA470M16
C6215 CFTLA103J50
C6211, C6254, C6403, C6417 CKSQYB102K50
C6201, C6205, C6210, C6237, C6276 CKSQYB103K50
C6278, C6280, C6281, C6402, C6409 CKSQYB103K50
C6418 CKSQYB103K50
C6251, C6252 CKSQYB153K50
C6203, C6259 CKSQYB223K50
C6228 CKSQYB472K50
C6209 CKSQYB473K50
C6230 CKSQYB821K50
C6218, C6223, C6255 CKSQYF103Z50
C6220, C6226, C6242, C6256 CKSQYF223Z50
C6225 CKSQYF473Z50
RESISTORS
R6280 RD1/4PU101J
R6413, R6416, R6418, R6906, R6909 RS1/8S0R0J
R6401 RS1/8S470J
VR6201 (10kΩ) PCP1029
Other Resistors RS1/10S J
OTHERS
BN6202 4P ANTENNA TERMINAL AKE7025
X6202 CERAMIC RESONATOR ASS1066
(456kHz)
X6201 CRYSTAL RESONATOR ASS1093
(7.2000MHz)
CN6201 14P SOCKET KP200IA14L
MW RF TUNING BLOCK AXX7041
CD ASSY
(1) CONTRAST TABLE
XWZ3141 and XWZ3050 are constructed the same except
for the following :
B
Mark
Symbol and
Part No.
Remarks
Description
XWZ3141 XWZ3050
C8310 CCSQCH180J50 CCSQCH150J50
R8305 RS1/10S331J RS1/10S0R0J
R8310 RS1/10S102J Not used
CN8004 HLEM22R-1 HLEM20R-1
X8301
(16.9344MHz)
PSS1008 DSS1083
