Pioneer XR-A330 Service Manual

48
XR-A660, XR-A330
Mark No. Description Part No.
Mark No. Description Part No.
D71, D72 S5688G
COILS AND FILTERS
L3331, L3332 ATH-133
L2801 ATX7002
L1651, L3991 LAU4R7J
L2301, L2302 LTA822J
F2201, F2202 RTF1209
SWITCHES AND RELAYS
RY3601 ASR7008
CAPACITORS
C2303, C2304 (270pF) ACG7024
C2301, C2302 CCSQCH100D50
C3047, C3048 CCSQCH101J50
C2192 CCSQCH220J50
C3319, C3320 CCSQCH3R0C50
C3311, C3312 CEANL1R0M50
C3317, C3318 CEANP220M35
C3621 CEANP2R2M2A
C3313, C3314 CEANP2R2M50
C2207, C2803, C2810, C3045, C3046 CEAT100M50
C3081, C3091, C33, C35, C3602 CEAT100M50
C43 CEAT100M50
C2002, C2316 CEAT101M16
C71 CEAT101M2A
C3303, C3304 CEAT101M50
C2312, C2313, C3035, C3036 CEAT1R0M50
C3107, C3108, C32, C42 CEAT1R0M50
C2106, C2214, C2215, C2321, C2322 CEAT220M50
C72 CEAT220M50
C2001, C3601 CEAT221M16
C41 CEAT222M25
C31 CEAT222M35
C2201, C2202, C2205, C2206 CEAT2R2M50
C2212, C2213, C2319, C2320 CEAT2R2M50
C3005–C3012, C3015–C3018 CEAT2R2M50
C3039, C3040, C3104 CEAT2R2M50
C2804, C2805, C3105 CEAT330M16
C3106, C3109 CEAT4R7M50
C3021, C3022 CEATR10M50
C2203, C2204, C3101, C3102 CEATR22M50
C3325 CEATR47M50
C3027, C3028 CFTLA334J50
C3023, C3024 CFTLA474J50
C2802 CKCYB681K2H
C5892 CKSQYB102K50
C2315, C2317, C2318, C3053, C3098 CKSQYB103K50
C3103 CKSQYB103K50
C1651, C2191, C2193, C3099, C5891 CKSQYB104K25
C2194 CKSQYB105K10
C3033, C3034 CKSQYB122K50
C2208, C2209 CKSQYB152K50
C3315, C3316 CKSQYB222K50
C2323, C2326 CKSQYB223K50
C3029, C3030 CKSQYB273K50
C2808, C2809 CKSQYB332K50
C2333, C2334 CKSQYB392K50
C2807 CKSQYB472K50
C3111, C3112 CKSQYB473K25
C2307, C2308, C2331, C2332 CKSQYB681K50
C3013, C3014 CKSQYB681K50
MOTOR ASSY
SWITCHES AND RELAYS
S8503 ASG7009
OTHERS
J8502 JUMPER WIRE 4P D20PWW0405E
MOTOR PULLEY PNW1634
CARRIAGE MOTOR VXM1033
SW ASSY
SWITCHES AND RELAYS
S8502 ASG7009
S8501 DSG1017
OTHERS
J8501 JUMPER WIRE 6P D20PWY0610E
AF ASSY (XWZ3089)
SEMICONDUCTORS
IC2101, IC3101–IC3103, IC5691 BA4558F-HT
IC5891, IC5892 BU4094BCF
IC2201 HA12136AF
IC2301 HA12211NT
IC3001 LC75394NED
IC42 NJM7805FA
IC32 NJM7812FA
IC3301 STK407-070B
Q3354, Q3601, Q3621 2SA1037K
Q71 2SA965
Q2806 2SB1197K
Q2803, Q2804 2SC1815
Q2801 2SC2240
Q2102, Q2201, Q2202, Q3101, Q3102 2SC2412K
Q3353, Q3603, Q3605–Q3608 2SC2412K
Q3081 2SD1858X
Q31 2SD2012
Q2203, Q2204, Q2805, Q3311, Q3312 2SD2114K
Q2301, Q2302 2SK368
Q3313 DTA124EK
Q2104, Q2105, Q3314 DTC124EK
Q2103, Q2306, Q2802, Q2807 DTC143EK
Q3351 IRFI9Z34G
Q3352 IRFIZ34G
D3301, D3302 1SR139-100
D2191, D2301–D2306, D3101, D3102 1SS133
D3351–D3354, D3361, D3362, D3601 1SS133
D3603, D3604, D3621, D3622 1SS133
D3625, D3626, D5891, D73 1SS133
D2102, D2103, D2201, D2202, D3051 1SS355
D3355, D3356 20E2-FC
D3357, D3358 MTZJ10C
D3083 MTZJ11C
D35, D36 MTZJ15C
D3359, D3360 MTZJ18B
D74 MTZJ33C
D3363, D3364 MTZJ39C
D2001 MTZJ6.2A
D48 MTZJ6.8C
D75 MTZJ8.2B
D
E
C
