Pioneer XR-A330 Service Manual

50
XR-A660, XR-A330
Mark No. Description Part No.
Mark No. Description Part No.
C2323, C2326, C3029, C3030 CKSQYB273K50
C2808, C2809 CKSQYB332K50
C2333, C2334 CKSQYB392K50
C2807 CKSQYB472K50
C2331, C2332, C3013, C3014 CKSQYB681K50
C3019, C3020, C3031, C3032 CKSQYB682K50
C3025, C3026 CKSQYB683K25
C3331–C3333 CKSQYF104Z50
C2801 CQHA822J2A
C2806 CQMBA223J50
RESISTORS
R2812 RD1/2LMF270J
R2809 RD1/2LMF4R7J
R72 RD1/2PM222J
R3333, R3334 RD1/4LMF100J
R3353, R3354 RD1/4PU101J
R73 RD1/4PU103J
R3081 RD1/4PU221J
R3317, R3318 RD1/4PU683J
R3991, R3992 RS2LMF331J
R3601, R3602 RS2LMFR22J
VR2802 (100kΩ) VCP1162
Other Resistors RS1/10S J
OTHERS
15P CABLE HOLDER 51063-1505
CN1051 20P FFC CONNECTOR 52045-2045
CN5102 38P FFC CONNECTOR 52045-3845
CN81 4P JUMPER CONNECTOR 52147-0410
CN3331 4P SPEAKER TERMINAL AKE7001
CN2302 KR CONNECTOR B2B-PH-K-S
CN2303 KR CONNECTOR B3B-PH-K-R
CN2301 KR CONNECTOR 3P B3B-PH-K-S
CN3051 14P PLUG KM200IB14
JA3001 2P PIN JACK VKB1060
CN3991 HEADPHONE JACK XKN3001
SECONDARY ASSY
(1) CONTRAST TABLE
XWZ3084 and XWZ3046 are constructed the same except
for the following :
(2) PARTS LIST FOR XWZ3084
SEMICONDUCTORS
IC71 (1.25A) AEK7010
IC31, IC41 (3A) AEK7015
IC11, IC12 (7A) AEK7021
IC21, IC22 (5A) AEK7046
D11, D21 GBU4DL-5303
D31–D34, D41–D44 S5688G
CAPACITORS
C11, C12 (220µF/63V) ACH7071
C21, C22 CEAT332M50
OTHERS
15P CABLE HOLDER 51063-1505
J11 JUMPER WIRE D15A15-350-2651
PRIMARY ASSY
Although XWZ3059 and XWZ3051 are different in part
number, they consist of the same components.
PARTS LIST FOR XWZ3059
CAPACITORS
C3 (10000pF/AC250V) ACG7020
SUB TRANS ASSY
(1) CONTRAST TABLE
XWZ3060 and XWZ3052 are constructed the same except
for the following :
(2) PARTS LIST FOR XWZ3060
SEMICONDUCTORS
IC81 NJM7805FA
Q81 2SD1859X
D85, D88–D90 1SS133
D81–D84 S5688G
TRANSFORMERS
T2 ATT7027
SWITCHES AND RELAYS
RY81 ASR7018
CAPACITORS
C83 CEAT100M50
C82 CEAT102M25
RESISTORS
R1 (2.2MΩ/ 1/2W) RCN1080
Other Resistors RD1/4PU J
OTHERS
4P CABLE HOLDER 51048-0400
AN1 1P AC INLET AKP7032
H1, H2 FUSE CLIP AKR7001
J81 JUMPER WIRE 4P D20PYY0425E
KN1 EARTH METAL FITTING VNF1084
F
G
Mark Symbol and Description
Part No.
Remarks
XWZ3084 XWZ3046
IC11,IC12 PROTECTOR AEK7021 AEK7019
(7A) (5A)
IC21,IC22 PROTECTOR AEK7046 AEK7053
(5A) (4A)
C21,C22 CEAT332M50 CEAT222M50
H
Mark Symbol and Description
Part No.
Remarks
XWZ3060 XWZ3052
R1 (2.2MΩ/ 1/2W) RCN1080 Not used
AN1 1P AC INLET AKP7032 BKP1046
KN1 VNF1084 Not used
EARTH METAL FITTING
