Pioneer XR-A330 Service Manual

51
XR-A660, XR-A330
Mark No. Description Part No.
Mark No. Description Part No.
R2907, R2909, R2910, R5611, R5919 RD1/4PU102J
R5915 RD1/4PU181J
R5925 RD1/4PU331J
R5605, R5606, R5612, R5613, R5926 RD1/4PU561J
R2902, R5604, R5607–R5610 RD1/4PU681J
R5927 RD1/4PU821J
R2911–R2913 RS1/8S0R0J
R5702 RS1/8S223J
R5614 RS1/8S331J
R2905 RS1/8S681J
Other Resistors RS1/10S J
OTHERS
CN2901 19P FFC CONNECTOR 52045-1945
CN5501 38P FFC CONNECTOR 52045-3845
X5901 REMOTE RECEIVER UNIT GP1U28X
V5621 FL TUBE XAV3004
2902 FL HOLDER XNG3008
X5501 CERAMIC RESONATOR RSS1050
(6MHz)
DISPLAY ASSY (XWZ3058 and XWZ3047)
(1) CONTRAST TABLE
XWZ3058 and XWZ3047 are constructed the same except
for the following :
(2) PARTS LIST FOR XWZ3058
SEMICONDUCTORS
IC5501 PDC048B
Q5501 2SA1037K
Q2903, Q2906, Q2908 2SB1132
Q5604, Q5801 2SC2412K
Q2910, Q2911 DTA124EK
Q5606 DTC124EK
Q2901, Q2904, Q2907, Q5502 DTC143EK
Q5601–Q5603, Q5605, Q5821 DTC143EK
D5631, D5811 1SS133
D5551–D5554, D5563–D5568 1SS181
D2901–D2903, D5569, D5570, D5597 1SS355
D5626, D5901 1SS355
D5602 SLP3118C51H
D5601 SLP7118C51H
D5603, D5604, D5621 SLP9118C51H
COILS AND FILTERS
L5811 LAU220J
SWITCHES AND RELAYS
S5951 ASX7004
S5952 ASX7017
S5911–S5915, S5917–S5925 XSG3001
S5927–S5936 XSG3001
CAPACITORS
C5812 (0.047F/5.5V) ACH1246
C5821 CEJA100M16
C5803 CEJA1R0M50
C5510, C5811, C5814 CEJA470M16
C5804 CKSQYB102K50
DISPLAY ASSY (XWZ3092 and XWZ3110)
(1) CONTRAST TABLE
XWZ3092 and XWZ3110 are constructed the same except
for the following :
(2) PARTS LIST FOR XWZ3092
SEMICONDUCTORS
IC5631 BA3835F
IC5601 BU2092F
IC5501 PDC048B
Q5501 2SA1037K
Q2903, Q2906, Q2908 2SB1132
Q5604, Q5801 2SC2412K
Q2910, Q2911 DTA124EK
Q5606 DTC124EK
Q2901, Q2904, Q2907, Q5502, Q5603 DTC143EK
Q5821 DTC143EK
D5593, D5811 1SS133
D5551–D5554, D5561–D5568 1SS181
D2901–D2903, D5569, D5570, D5597 1SS355
D5626, D5901 1SS355
D5612 BR5064X
D5608–D5611 MBG5064X
D5613–D5616 MPG5064X
D5617–D5620 SLP3118C51H
D5603–D5607, D5621 SLP9118C51H
COILS AND FILTERS
L5811 LAU220J
SWITCHES AND RELAYS
S5951 ASX7004
S5952 ASX7017
S5911–S5931 XSG3001
CAPACITORS
C5812 (0.047F/5.5V) ACH1246
C5601 CCSQSL151J50
C5821 CEJA100M16
C5803 CEJA1R0M50
C5510, C5811, C5814 CEJA470M16
C5804 CKSQYB102K50
C5995, C5996 CKSQYB103K50
C5816, C5997–C5999 CKSQYB104K25
C5509, C5951–C5954 CKSQYB471K50
C5506–C5508 CKSQYB472K50
C5602, C5631–C5634, C5901 CKSQYF104Z50
C5503, C5504, C5813, C5822 CKSQYF473Z50
RESISTORS
R5529 (470Ω) ACN7056
R5554, R5561, R5562 (1.5kΩ) ACN7062
R5558, R5563, R5564 (47kΩ) ACN7077
R5508 RA11T104J
R5506 RA7T104J
I
I
Mark Symbol and Description
Part No.
Remarks
XWZ3092 XWZ3110
D5597 1SS355 Not used
Mark Symbol and Description
Part No.
Remarks
XWZ3058 XWZ3047
D5597 1SS355 Not used
