Pioneer XR-A330 Service Manual

52
XR-A660, XR-A330
Mark No. Description Part No.
Mark No. Description Part No.
C5995, C5996 CKSQYB103K50
C5816, C5997–C5999 CKSQYB104K25
C5509, C5951–C5954 CKSQYB471K50
C5506–C5508 CKSQYB472K50
C5634, C5901 CKSQYF104Z50
C5625 CKSQYF224Z25
C5503, C5504, C5813, C5822 CKSQYF473Z50
RESISTORS
R5529 (470Ω) ACN7056
R5554, R5561, R5562 (1.5Ω) ACN7062
R5558, R5563, R5564 (47kΩ) ACN7077
R5508 RA11T104J
R5506 RA7T104J
R2907, R2909, R2910, R5919 RD1/4PU102J
R5915 RD1/4PU181J
R5925 RD1/4PU331J
R5926 RD1/4PU561J
R2902 RD1/4PU681J
R5927 RD1/4PU821J
R2911–R2913, R5567 RS1/8S0R0J
R5702 RS1/8S223J
R5614 RS1/8S331J
R2905 RS1/8S681J
Other Resistors RS1/10S J
OTHERS
CN2901 17P FFC CONNECTOR 52045-1745
CN5501 38P FFC CONNECTOR 52045-3845
X5901 REMOTE RECEIVER UNIT GP1U28X
5631 FL HOLDER VNF1096
V5621 FL TUBE XAV3003
X5501 CERAMIC RESONATOR RSS1050
(6MHz)
CD SW LED ASSY
SEMICONDUCTORS
D5623 SLP3118C51H
D5624 SLP7118C51H
D5622 SLP9118C51H
SWITCHES AND RELAYS
S5937–S5941 XSG3001
RESISTORS
All Resistors RS1/10S J
OTHERS
J5501 JUMPER WIRE D20PWW0615E
J

Pioneer XR-A330 Specifications

General

Brand	Pioneer
Model	XR-A330
Category	Cassette Player
Language	English
