XR-A6800, XR-A4800
2.1 PACKING
2. EXPLODED VIEWS AND PARTS LIST
NOTES:
•
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
•
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
•
Screws adjacent to mark on the product are used for disassembly.
1 Power Cord See Contrast table (2)
2 FM Antenna ADH7005
3 AM Loop Antenna XTB3001
4 Remote Control Unit XZN3106
5 Battery Cover XZN3103
NSP 6 Dry Cell Battery (R6P, AA) VEM-013
7 Packing Sheet AHG7049
8 Front Pad XHA3018
9 Rear Pad XHA3019
10 Packing Case See Contrast table (2)
NSP 11 Warranty Card ARY7022
12 Polyethylene Bag Z21-038
(0.03 × 230 × 340)
13 Operating Instructions XRE3030
(English/French)
14 Operating Instructions See Contrast table (2)
(Italian/Dutch/German)
15 Operating Instructions See Contrast table (2)
(Portuguese/Swedish/Spanish)
NSP 16 Polyethylene Bag See Contrast table (2)
17 Fuse (T5A) See Contrast table (2)
(1) PACKING PARTS LIST
Mark No. Description Part No.
(2) CONTRAST TABLE
XR-A6800/MYXJ, XR-A4800/MYXJ and NVXJ are constructed the same except for the following :
Mark No. Symbol and Description
Part No.
Remarks
XR-A6800/MYXJ XR-A4800/MYXJ XR-A4800/NVXJ
NSP
1
10
14
15
16
17
Power Cord
Packing Case
Operating Instructions
(Italian/Dutch/German)
Operating Instructions
(Portuguese/Swedish/Spanish)
Polyethylene Bag
Fuse (T5A)
ADG1154
XHD3143
XRC3020
XRC3021
Not used
Not used
ADG1154
XHD3142
XRC3020
XRC3021
Not used
Not used
ADG1156
XHD3142
Not used
Not used
AHG7033
AEK7001
