64
XR-A6800, XR-A4800
FITTING THE PULLEY INTO THE CARRIAGE MOTOR
Clamper Holder
Actuater
Servo Base
Hook
Clamper Holder
$M Mechanism CD
Actuater
Hook
Hook
Servo Mechanism
Assy
Servo Base
Hook
Carriage Motor
Motor Pulley
Servicing pulley press-in station
Loading Tray
For replacement of the carriage motor,
fit the motor pulley by using the servicing
pulley press-in station located on the loading
tray, as shown in the figure on the right.
1
2
1
2
1
1
2
