XR-A6800, XR-A4800
1 AF Assy See Contrast table (2)
2 SECONDARY Assy See Contrast table (2)
3 PRIMARY Assy See Contrast table (2)
4 FM/AM TUNER Module AXQ7068
NSP 5 $M MECHANISM CD-2 See Contrast table (2)
6 Ceramic Capacitor (C1) CKPUYB102K50
7 Power Transformer (T1) See Contrast table (2)
8 Fuse (FU2) See Contrast table (2)
9 Flexible Cable (08P) XDD3048
10 • • • • •
11 • • • • •
12 • • • • •
13 PCB Bracket ANG7263
NSP 14 Chassis XNA3005
15 Rear Panel See Contrast table (2)
16 PCB Bracket XNG3006
17 Earth Plate XNG3015
18 Heat Sink See Contrast table (2)
19 Sub Heat Sink B XNH3012
20 • • • • •
21 Cushion Leg A XEB3008
22 Wire Clip A XEC3003
23 Card Spacer XEC3008
24 Leg XMR3012
25 SEC Holder A See Contrast table (2)
(1) EXTERIOR SECTION PARTS LIST
Mark No. Description Part No. Mark No. Description Part No.
26 Tray Cap Assy XAK3156
27 Pioneer Badge XAM3001
28 Bonnet Case XZN3098
NSP 29 Fuse Card See Contrast table (2)
30 Caution Label HE See Contrast table (2)
31 Caution Label See Contrast table (2)
32 Disc Label XAX3127
33 ICP Label See Contrast table (2)
34 ICP Label See Contrast table (2)
35 ICP Label See Contrast table (2)
NSP 36 Getter See Contrast table (2)
NSP 37 DO NOT THROW Assy • • • • •
NSP 38 CABLE HOLDER Assy • • • • •
39 Screw BBZ30P080FMC
40 Screw BBZ30P180FMC
41 Screw ASZ40P060FMC
42 Screw BPZ30P080FMC
43 Screw VBZ30P080FZK
44 Barier XEC3013
45 Screw BPZ30P100FZK
46 Screw VBT30P080FZK
(2) CONTRAST TABLE
XR-A6800/MYXJ, XR-A4800/MYXJ and NVXJ are constructed the same except for the following :
Mark No. Symbol and Description
Part No.
Remarks
XR-A6800/MYXJ XR-A4800/MYXJ XR-A4800/NVXJ
NSP
NSP
NSP
1
2
3
5
7
8
15
18
25
29
30
31
33
34
35
36
AF Assy
SECONDARY Assy
PRIMARY Assy
$M MECHANISM CD-2
Power Transformer (T1)
Fuse (FU2)
Rear Panel
Heat Sink
SEC Holder A
Fuse Card
Caution Label HE
Caution Label
ICP Label
ICP Label
ICP Label
Getter
XWZ3310
XWZ3304
XWZ3312
XXA3012
XTS3037
AEK1061 (T5A)
XNC3058
XNH3010
XMR3014
AAX7098
PRW1233
VRW1094
XAX3121
XAX3153
XAX3158
XAX3169
XWZ3297
XWZ3289
XWZ3299
XXA3009
XTS3036
AEK1060 (T4A)
XNC3053
XNH3009
XMR3015
Not used
PRW1233
VRW1094
Not used
Not used
Not used
XAX3163
XWZ3297
XWZ3289
XWZ3299
XXA3009
XTS3036
AEK1060 (T4A)
XNC3053
XNH3009
XMR3015
Not used
PRW1018
Not used
Not used
Not used
Not used
XAX3163
