7
XR-A6800, XR-A4800
(1) FRONT PANEL SECTION PARTS LIST
Mark No. Description Part No. Mark No. Description Part No.
1 DISPLAY Assy See Contrast table (2)
2 BLUE LED Assy XWZ3292
3 Deck Mechanism Unit XYM3012
4 Flexible Cable 27P XDD3041
5 Flexible Cable 15P XDD3050
6 Flexible Cable 19P XDD3051
7 GND Plate B XNG3031
8 GND Plate C See Contrast table (2)
9 Ratch Spring_L ABH7130
10 Ratch Spring_R ABH7131
11 Damper Assy XXA3025
12 Door Spring_L XBH3010
13 Door Spring_R XBH3011
14 Cushion Leg A XEB3008
15 Cushion Spring XEB3010
16 Ratch Mold_L XMR3001
17 Ratch Mold_R XMR3002
18 Volume Knob XAA3013
19 JOG Knob XAA3015
20 MIC Knob XAB3007
21 FUNC Button L See Contrast table (2)
22 FUNC Button R See Contrast table (2)
23 FUNC Frame L XAD3052
24 FUNC Frame R XAD3053
25 CD ENT Button XAD3055
26 Display Panel See Contrast table (2)
27 EQ Panel See Contrast table (2)
28 JOG Lens XAK3152
29 V Lens XAK3153
30 LT Conductor XAK3155
31 • • • • •
32 FL Filter XAK3162
33 FL Cover XAK3163
34 Cover Sheet L XAK3184
35 Cover Sheet R XAK3185
36 Power Button See Contrast table (2)
37 CD Button XAD3045
38 SC Button XAD3046
39 SC Button L XAD3047
40 SC Button R XAD3048
41 DOLBY Button XAD3054
42 Sub Panel See Contrast table (2)
43 ST Lens XAK3151
44 Deck Lens L XAK3159
45 Deck Lens R XAK3160
46 JOG Conductor XAK3165
47 Deck Door_L See Contrast table (2)
48 Deck Door_R See Contrast table (2)
49 Front Panel XMB3026
50 • • • • •
51 GND Plate A See Contrast table (2)
52 Spacer XEB3012
53 Spacer XEB3013
54 Spacer XEB3011
55 Screw BPZ30P080FMC
56 Connector Assy 3P XDE3037
57 Connector Assy 5P XDE3038
(2) CONTRAST TABLE
XR-A6800/MYXJ, XR-A4800/MYXJ and NVXJ are constructed the same except for the following :
Mark No. Symbol and Description
Part No.
Remarks
XR-A6800/MYXJ XR-A4800/MYXJ XR-A4800/NVXJ
1
8
21
22
26
27
36
42
47
48
51
DISPLAY Assy
GND Plate C
FUNC Button L
FUNC Button R
Display Panel
EQ Panel
Power Button
Sub Panel
Deck Door_L
Deck Door_R
GND Plate A
XWZ3311
XNG3047
XAD3050
XAD3051
XAK3130
XAK3150
XAD3044
XAK3142
XAN3022
XAN3026
Not used
XWZ3298
Not used
XAD3076
XAD3077
XAK3125
XAK3149
XAD3043
XAK3137
XAN3021
XAN3025
XNG3030
XWZ3298
Not used
XAD3076
XAD3077
XAK3125
XAK3149
XAD3043
XAK3137
XAN3021
XAN3025
XNG3030
