XR-VS400
2
1. CONTRAST OF MISCELLANEOUS PARTS
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
Reference Nos. indicate the pages and Nos. in the service manual for the base model.
NOTES:
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
561
473
R50
1R0
5621
560
47k
0.5
1
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 10
3
R50
1R0
561
473
5.62k RN1/4PC F562 x 10
1
5621
CONTRAST TABLE
XR-VS400/DXJN/NC and XR-VS90SW/DBDXJ are constructed the same except for the following :
Part No.
Ref. No. Mark Symbol and Description XR-VS90SW XR-VS400 Remarks
/DBDXJ /DXJN/NC
PCB ASSEMBLIES
MAIN ASSY XWM3164 AWM7604
P5- 1 AF ASSY XWZ3313 AWU7788
COMPLEX ASSY XWM3170 AWM7616
P5- 3 PRIMARY ASSY XWZ3291 AWU7965
P7- 1 DISPLAY ASSY XWZ3315 AWU7799
P5- 4 FM/AM TUNER Module AXQ7062 AXQ7065 *1
PACKING SECTION
P3- 1 Power Cord ADG1158 ADG1154
P3- 4 Remote Control Unit XZN3107 XZN3121
P3- 8 Front Pad XHA3018 XHA3028
P3- 9 Rear Pad XHA3019 XHA3029
P3-10 Packing Case XHD3132 XHD3276
P3-12 Operating Instructions (English/Chinese/Spanish) XRE3034 Not used
P3-12 Operating Instructions (Thai) Not used XRC3047
P3-14 SW Wire Antenna ADH7006 Not used
Caution Sheet XRH3003 Not used
EXTERIOR SECTION
P5- 5 NSP $M MECHA. VCD XXA3017 Not used
P5- 5 NSP $M MECHA. VCD/MP3 Not used AXA7107
P5-11 Tray Cap XAK3156 XAK3236
Tray Panel CD Not used XAK3235 For Tray Cap
P5-15 Rear Panel XNC3062 XNC3135
P5-26 NSP Tray Cap Assy XXG3046 Not used
P5-31 Caution Label Not used PRW1018
P5-36 NSP Getter XAX3173 XAX3268
P5-44 Barrier XEC3013 XEC3027
NSP Name Label XAL3048 XAL3098
Rear Sheet AED7037 Not used
FRONT PANEL SECTION
P7-8 GND Plate C XNG3047 Not used
P7-18 Volume Knob XAA3013 XAA3022
P7-21 FUNC Button L XAD3050 XAD3111 No.8
FUNC Cap L Not used XAK3247 No.7
P7-22 FUNC Button R XAD3051 XAD3112 No.10
To Next Page
