XR-VS400
3
Notes : For PCB ASSEMBLIES, Refer to “CONTRAST OF PCB ASSEMBLIES” and “2. SCHEMATIC DIAGRAM”.
The numbers in the remarks column correspond to the numbers on the “ FRONT PANEL ASSY ”.
*1 Refer to XR-VS90/DLXJ/NC.
Part No.
Ref. No. Mark Symbol and Description XR-VS90SW XR-VS400 Remarks
/DBDXJ /DXJN/NC
FUNC Cap R Not used XAK3248 No.9
P7-23 FUNC Frame L XAD3052 Not used
P7-24 FUNC Frame R XAD3053 Not used
P7-25 CD ENT Button XAD3055 XAD3109 No.12
P7-26 Display Panel XAK3233 XAK3318
P7-27 EQ Panel XAK3150 Not used
SC Panel Not used XAK3268 No.26
SC Panel Assy Not used XXG3090 No.13
P7-28 JOG Lens XAK3152 XAK3243 No.23
P7-29 V Lens XAK3153 XAK3313
P7-33 FL Cover XAK3163 XAK3239
P7-34 Cover Sheet L XAK3184 Not used
P7-35 Cover Sheet R XAK3185 Not used
LED Barrier Not used XEC3022 No.24
P7-36 Power Button XAD3043 XAD3102 No.17
P7-37 CD Button XAD3045 XAD3104 No.19
P7-38 SC Button XAD3046 Not used
SC Button L Not used XAD3105 No.29
SC Cap L Not used XAK3241 No.27
SC Button R Not used XAD3106 No.30
SC Cap R Not used XAK3267 No.28
ASES Button Not used XAD3114 No.20
Timer Button Not used XAD3115 No.21
P7-39 SC Button L XAD3047 Not used
Audio Button Not used XAD3107 No.14
P7-40 SC Button R XAD3048 Not used
Visual Button Not used XAD3108 No.15
P7-41 DOLBY Button XAD3054 XAD3121 No.11
P7-42 Sub Panel XAK3201 XAK3307 No.6
P7-43 Standby Lens XAK3151 XAK3240 No.18
P7-44 Deck Lens L XAK3159 XAK3249 No.3
P7-45 Deck Lens R XAK3160 XAK3250 No.5
P7-46 JOG Conductor XAK3165 XAK3244 No.22
P7-47 Deck Door_L XAN3022 XAN3037 No.2
P7-48 Deck Door_R XAN3026 XAN3038 No.4
P7-49 Front Panel XMB3026 XMB3056 No.1
O/C Button Not used XAD3103 No.16
P7-50 NSP Front Panel Assy XXG3065 XXG3116
P7-51 GND Plate A Not used XNG3030
P7-52 Spacer XEB3012 Not used
P7-53 Spacer XEB3013 Not used
P7-59 Cushion Spacer XEB3015 Not used
P7-60 Cushion Spacer XEB3016 Not used
P7-61 Cushion Spacer XEB3017 Not used
Spacer XEC3014 Not used
Spacer XEC3019 Not used
To Next Page
