79
XR-A9800D
Fig.7 Adjustment and Measurement Points
FRONT
TAPE TEST
POINT
L ch
R ch
VR2303 VR2305
VR2304 VR2306
VR2302
VR2301
VR2802
VR2801
L2801
SIDE A
AF ASSY
A
