XR-VS500D, XR-VS300D
3
2. CONTRAST OF MISCELLANEOUS PARTS
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
Reference Nos. indicate the pages and Nos. in the service manual for the base model.
NOTES:
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
561
473
R50
1R0
5621
560
47k
0.5
1
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 10
3
R50
1R0
561
473
5.62k RN1/4PC F562 x 10
1
5621
CONTRAST TABLE for XR-VS500D
XR-VS500D/DBXJN, DDXJN/RA, DDXJN/RB, DDXJN/RD, DLXJN/NC and XR-A9800D/KUCXJ are constructed the
same except for the following :
Part No.
Ref. No. Mark Symbol and Description
XR-A9800D XR-VS500D XR-VS500DXR-VS500D XR-VS500DXR-VS500D Remarks
/KUCXJ /DBXJN /DDXJN/RA /DDXJN/RB /DDXJN/RD /DLXJN/NC
PCB ASSEMBLIES
MAIN ASSY XWM3174 XWM3172 XWM3172 XWM3172 XWM3172 XWM3172
P5- 1 AF ASSY XWZ3330 XWZ3322 XWZ3322 XWZ3322 XWZ3322 XWZ3322
COMPLEX ASSY XWM3178 XWM3176 XWM3176 XWM3176 XWM3176 XWM3176
P5- 4 PRIMARY ASSY XWZ3332 XWZ3326 XWZ3326 XWZ3326 XWZ3326 XWZ3326
P7- 1 DISPLAY ASSY XWZ3331 XWZ3324 XWZ3324 XWZ3324 XWZ3324 XWZ3324
PACKING SECTION
P3- 1 Power Cord ADG7022 ADG1158 ADG1158 ADG1158 ADG1158 ADG1154
P3- 5 Remote Control Unit XZN3109 XZN3110 XZN3110 XZN3110 XZN3110 XZN3110
P3-11 Packing Case XHD3144 XHD3166 XHD3166 XHD3166 XHD3166 XHD3167
P3-12 NSP Warranty Card ARY7045 Not used Not used Not used Not used Not used
P3-14 Operating Instructions XRE3036 Not used Not used Not used Not used Not used
(English/French)
Operating Instructions Not used XRE3035 XRE3035 XRE3035 XRE3035 XRE3035
(English/Chinese)
Operating Instructions Not used Not used XRC3022 XRC3022 XRC3022 Not used
(Spanish/Arabian)
Region Label Not used Not used VRW1708 VRW1701 VRW1705 Not used For Packing Case
Caution Sheet Not used Not used XRH3001 Not used XRH3001 Not used Accessories
EXTERIOR SECTION
P5-12
Power Transformer (T1) (AC120V) XTS3042 Not used Not used Not used Not used Not used
P5-12
Power Transformer (T1) Not used XTS3038 XTS3038 XTS3038 XTS3038 XTS3038
(AC110-127V/220-230V/240V)
P5-13
Fuse (FU1 : 6.3A) REK1085 Not used Not used Not used Not used Not used
P5-13
Fuse (FU1 : T5A) Not used AEK1061 AEK1061 AEK1061 AEK1061 AEK1061
P5-25 Rear Panel XNC3065 XNC3066 XNC3066 XNC3066 XNC3066 XNC3067
P5-26 SEC Holder XMR3032 XMR3035 XMR3035 XMR3035 XMR3035 XMR3035
P5-38 Tray Cap XAK3157 XAK3210 XAK3210 XAK3210 XAK3210 XAK3210
P5-41 NSP Fuse Card AAX2374 Not used Not used Not used Not used Not used
P5-42 NSP Getter XAX3175 XAX3176 XAX3176 XAX3176 XAX3176 XAX3176
P5-43 65 Label ARW7050 Not used Not used Not used Not used Not used
Fuse (FU2, FU3 : T3.15A) Not used AEK1059 AEK1059 AEK1059 AEK1059 AEK1059 *1
NSP Name Label Not used XAL3067 XAL3068 XAL3068 XAL3068 Not used *2
NSP Region Label Not used Not used XAX3183 XAX3184 XAX3185 Not used For Rear Panel
Caution Label Not used Not used Not used Not used Not used PRW1018 *3
NSP SISIR Label Not used Not used Not used Not used Not used XAX3181 For Rear Panel
FRONT PANEL SECTION
P7-19 JOG Knob XAA3015 XAA3019 XAA3019 XAA3019 XAA3019 XAA3019
P7-21 FUNC Button L XAD3061 XAD3089 XAD3089 XAD3089 XAD3089 XAD3089
P7-22 FUNC Button R XAD3051 XAD3090 XAD3090 XAD3090 XAD3090 XAD3090
P7-23 FUNC Frame L XAD3052 XAD3091 XAD3091 XAD3091 XAD3091 XAD3091
P7-24 FUNC Frame R XAD3053 XAD3092 XAD3092 XAD3092 XAD3092 XAD3092
