Pioneer XR-VS500D User Manual

89
XR-A9800D
Remove a Bonnet (Eleven screws).
1
7.1.4 DISASSEMBLY
DVD MAIN ASSY
Note:
The loading tray can be pulled out
when the main cam is in this position.
(The Lock Lever should be in the notch
of the Main Cam.)
3
4
5
8
× 3
Unhook
Tray Cap
$M MECHA. DVD (5P)
$M DVD Mecha Unit
DVD Shield
Rear
Front
PICKUP
Assy
AF Assy
CONNECT Assy(6 CH)
CN5104
CN8104
CN8105
From
CONNECT Assy(6 CH)
CN8103
From
DISPLAY
Assy
CN5502
From
REAR AMP
Assy
CN3404
11
10
12
13
12
8
9
6
× 4
Fitting
Main Cam
Lock Lever
2
ON
OFF
(at Disassembling)
7

Pioneer XR-VS500D Specifications

General

Brand	Pioneer
Model	XR-VS500D
Category	Stereo Receiver
Language	English
