107
XR-A9800D
TV
Press to switch your TV on or into standby.
TV CH +
Press to change the TV channel.
TV CH –
Press to change the TV channel.
TV VOL +
Press to turn up the TV volume.
TV VOL –
Press to turn down the TV volume.
TV/VIDEO
Press to switch the TVs input between the built in
TV tuner and an external video source.
V VOLUME +/–
Use to adjust the overall volume level.
8.2 SPECIFICATIONS
Amplifier Section
Continuous Power Output – Stereo
(XR-A9800D)
Continuous average power output of 70
watts* per channel, min., at 6 ohms, from
60 Hz to 15,000 Hz with no more than
5%** total harmonic distortion (front L/R).
* Measured pursuant to the Federal Trade
Commission’s Trade Regulation rule on Power
Output Claim’s for Amplifiers.
** Measured by Audio Spectrum Analyzer.
Surround
XR-A9800D, XR-VS500D (RMS)
Front ........................................................... 100 W per channel
(1 kHz, 10% T.H.D., 6 Ω)
Center, Rear R, L ......................................... 33 W per channel
(1 kHz, 10% T.H.D., 8 Ω)
Disc section
Digital audio characteristics................... DVD fs: 96 kHz, 24-bit
Type .......... DVD system, Video CD system and Compact Disc
digital audio system
Frequency response ..........................................4 Hz to 44 kHz
S/N ratio ..........................................................................95 dB
Dynamic range ................................................................ 95 dB
Total harmonic distortion ............................................. 0.005 %
Wow and Flutter .....................................Limit of measurement
................................... (±0.001 % W.PEAK) or less (EIAJ)
Cassette deck section
Systems............................................. 4 track, 2-channel stereo
Heads ......................................... Recording/playback head × 1
Playback head × 1
Motor ......................................................... DC servo motor × 1
Tape types ...........TYPE I (Normal)/TYPE II (HIGH/CrO2) tape
FM tuner section
FrequencyRange ................................... 87.5 MHz to 108 MHz
Antenna input ................................................ 75 Ω unbalanced
AM tuner section
FrequencyRange
With 9 kHz step............................... 531 kHz to 1,602 kHz
With 10 kHz step............................. 530 kHz to 1,700 kHz
Antenna input ..................................................... Loop antenna
Miscellaneous
Power Requirements
US and Canadian models .............................. AC 120 V, 60 Hz
Australian models ...................................... AC 240 V, 50/60 Hz
Power Consumption ....................................................... 170 W
Power Consumption in Standby mode ............................... 1 W
Dimensions............................ 270 (W) x 320 (H) x 339 (D) mm
............................. 10 5/8 (W) x 12 5/8 (H) x 13 3/8 (D) in.
Weight (without package) ......................... 10.2kg (22 lbs. 8oz.)
